Product Description
+−
Grade
Style
Run Watts
3,200
Rated Watts
Surge Watts
3,500
Starting Watts
Fuel
Engine
Robin Subaru
Grade
Semi-Pro
Style
Portable
Run Watts
3,200
Surge Watts
3,500 Starting Watts
Fuel
Gasoline
Engine
Robin Subaru
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
Features
Features
- Technologically-Advanced Overhead Cam (OHC) Engines
- Offer quieter operation, easier starting and increased longevity
- 100% Copper Windings
- Ensure high-performance with maximum surge capacity
- GFCI and Twist Lock Receptacles
- Enhance operator safety
- Hourmeter
- Convenient tracking device for important maintenance levels
- AVR (Automatic Voltage Regulator)
- Provides precise voltage control output on the generator
- Makes the system appropriate for sensitive electronic equipment
- Large Capacity Fuel Tank with Fuel Gauge
- Lets the operator know current fuel level
- New Wheel Kit w/ Flat-Free Tires
- Provides enhanced portability and convenience
- Low Oil Shutdown
- Automatically shuts off the engine when low oil level is detected
- U.S. Forestry-Approved Spark Arrestor
- Reduces the risk of spark-induced fires
Specifications
Plugs
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Alternator
Brush
Auto Voltage Regulation
Yes
Rated Watts
3200 Watts
Surge Watts
3500 Watts
Fuel Type
Gasoline
Rated Amps
13 Amps
Portability Kit
Pneumatic Wheels
Tank Size
4 Gallons
Run Time @ 50% Load
10.8 Hours
Fuel Tank Material
Metal
Fuel Gauge
Yes
Decibel Rating @ 7m
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
72 dbA
Hour Meter
Yes
Grade Type
Semi-Pro
Engine
Engine Brand
Robin Subaru
Starting System
Recoil Start
HP
7 HP
Consumer Engine Warranty
5 Years
Commercial Engine Warranty
5 Years
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
Overview
Assembly Required
Yes
Weight
137 Pounds
Consumer Warranty
3 Years
Commercial Warranty
3 Years
Product Style
Portable Generator
Product Length
28 Inches
Product Width
25 Inches
Product Height
26 Inches
UPC
859723000503
Plugs
NEMA 5-20R - GFCI
2
NEMA L14-30R
1
Grade
Style
Run Watts
3,200
Rated Watts
Surge Watts
3,500
Starting Watts
Fuel
Engine
Robin Subaru
Grade
Semi-Pro
Style
Portable
Run Watts
3,200
Surge Watts
3,500 Starting Watts
Fuel
Gasoline
Engine
Robin Subaru
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
Features
Features
- Technologically-Advanced Overhead Cam (OHC) Engines
- Offer quieter operation, easier starting and increased longevity
- 100% Copper Windings
- Ensure high-performance with maximum surge capacity
- GFCI and Twist Lock Receptacles
- Enhance operator safety
- Hourmeter
- Convenient tracking device for important maintenance levels
- AVR (Automatic Voltage Regulator)
- Provides precise voltage control output on the generator
- Makes the system appropriate for sensitive electronic equipment
- Large Capacity Fuel Tank with Fuel Gauge
- Lets the operator know current fuel level
- New Wheel Kit w/ Flat-Free Tires
- Provides enhanced portability and convenience
- Low Oil Shutdown
- Automatically shuts off the engine when low oil level is detected
- U.S. Forestry-Approved Spark Arrestor
- Reduces the risk of spark-induced fires
Specifications
Plugs
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Alternator
Brush
Auto Voltage Regulation
Yes
Rated Watts
3200 Watts
Surge Watts
3500 Watts
Fuel Type
Gasoline
Rated Amps
13 Amps
Portability Kit
Pneumatic Wheels
Tank Size
4 Gallons
Run Time @ 50% Load
10.8 Hours
Fuel Tank Material
Metal
Fuel Gauge
Yes
Decibel Rating @ 7m
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
72 dbA
Hour Meter
Yes
Grade Type
Semi-Pro
Engine
Engine Brand
Robin Subaru
Starting System
Recoil Start
HP
7 HP
Consumer Engine Warranty
5 Years
Commercial Engine Warranty
5 Years
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
Overview
Assembly Required
Yes
Weight
137 Pounds
Consumer Warranty
3 Years
Commercial Warranty
3 Years
Product Style
Portable Generator
Product Length
28 Inches
Product Width
25 Inches
Product Height
26 Inches
UPC
859723000503
Plugs
NEMA 5-20R - GFCI
2
NEMA L14-30R
1
Product Specs
+−
Specifications
Plugs
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Alternator
Brush
Auto Voltage Regulation
Yes
Rated Watts
3200 Watts
Surge Watts
3500 Watts
Fuel Type
Gasoline
Rated Amps
13 Amps
Portability Kit
Pneumatic Wheels
Tank Size
4 Gallons
Run Time @ 50% Load
10.8 Hours
Fuel Tank Material
Metal
Fuel Gauge
Yes
Decibel Rating @ 7m
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
72 dbA
Hour Meter
Yes
Grade Type
Semi-Pro
Engine
Engine Brand
Robin Subaru
Starting System
Recoil Start
HP
7 HP
Consumer Engine Warranty
5 Years
Commercial Engine Warranty
5 Years
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
Overview
Assembly Required
Yes
Weight
137 Pounds
Consumer Warranty
3 Years
Commercial Warranty
3 Years
Product Style
Portable Generator
Product Length
28 Inches
Product Width
25 Inches
Product Height
26 Inches
UPC
859723000503
Plugs
NEMA 5-20R - GFCI
2
NEMA L14-30R
1
Product Q&A
(1)
+−
Search Product Q&A's
Answered by Jared, the Generator Expert
+−
What is the weight and dimensions on the Subaru SGX3500 generator?
Bruce Sentell
from South Carolina
February 05, 2014
Answer
Thanks for your inquiry.
The weight for this unit is 121 Lbs. and the dimensions are 27L x 25W x 25H.
Below is a link to the Spec Sheet which will have this information and more.
Spec Sheet
The weight for this unit is 121 Lbs. and the dimensions are 27L x 25W x 25H.
Below is a link to the Spec Sheet which will have this information and more.
Spec Sheet
