Clarke RC240D-JD3FX - 191kW Industrial Towable Diesel Generator w/ John Deere Engine

Clarke RC240D-JD3FX - 191kW Industrial Towable Diesel Generator w/ John Deere Engine
Our Price
Compare Prices
Shipping Info
Model: RC240D-JD3FX
Product Discontinued
Sorry, this product is no longer available.
Discontinued
Sorry, this product is no longer available
Free Freight
Free Freight
*We currently CANNOT ship this product to Alaska, Hawaii, California or any destination outside of the United States
Share
  • Product Description
  • Reviews
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+−
Grade
Style
Run Watts
191,000
Rated Watts
Voltage
Voltage Selector Switch
Fuel
Engine
John Deere
Grade
Professional
Style
Tow-Behind
Run Watts
191,000
Voltage
Voltage Selector Switch
Fuel
Diesel
Engine
John Deere
Features
Features
  • Clarke Power Generation Industrial Mobile/Prime Generators
  • Manufactured in Greensboro, North Carolina, USA.
  • 6.8L John Deere PowerTech Plus™ Industrial Diesel Engine (6068HF485)
  • Reliable performance & fuel economy; EPA Tier 3 & CARB Certified
  • 253-Gallon Skid-Base Mounted Fuel Tank w/ Low-Fuel Shutdown
  • Provides a runtime of up to 36 hours & very balanced lifting
  • Racor-style fuel/water separator & fine micron secondary fuel filter
  • Leroy Somer Alternator w/ AREP Brushless Excitation (<5% THD)
  • Industry leading motor starting kVA & 300% overload capability
  • 3-Position Voltage Selector Switch w/ Operation Lock
  • Single Phase 120/139/240/277V & 3-Phase 208/240/416/480V
  • Digital Genset Controller w/ LCD Display
  • Easy to read fault codes w/ # & text explanations
  • Remote Auto Start/Stop (2-Wire, Closed Contact Logic)
  • Allows for connection to auto transfer switch or remote starting device
  • Tandem-Axle Trailer w/ 3" Pintle Hitch, Wheel Chocks & Jack Stand
  • 15" Wheels, torsion suspension, electric brakes & EZ Lube hubs
  • Steel Sound Attenuated Enclosure (69dB(A) @ 23' 100% Load)
  • Wide opening side access doors & center-point lifting eye
  • 1-Year / 2000 Hour Limited Warranty (See Spec Sheet)
Specifications
Plugs
NEMA 5-20R (GFCI)
NEMA 5-20R (GFCI)
CS6369 (50-Amp Twistlock)
CS6369 (50-Amp Twistlock)
CS6369 (50-Amp Twistlock)
Engine
Engine Brand
John Deere
Starting System
12-Volt Key Start
CC
6800 CC
Consumer Engine Warranty
1 Year
Commercial Engine Warranty
1 Year
Engine RPM
1800 RPM
Product Specs
Voltage
Voltage Selector Switch
Frequency
60 Hertz
Alternator
Brushless
Auto Voltage Regulation
Yes
Rated Watts
191000 Watts
Fuel Type
Diesel
Portability Kit
Pneumatic Wheels
Tank Size
253.7 Gallons
Run Time @ 50% Load
36 Hours
Fuel Gauge
Yes
Decibel Rating @ 7m ? Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
69 dbA
Hour Meter
Yes
Voltage Meter
Yes
Lifting Eye
Yes
Battery
Not Included
Grade Type
Professional
Plugs
NEMA 5-20R - GFCI
2
CS6369 - 50-Amp Twistlock
3
Overview
Made in USA
Yes
Weight
7717 Pounds
Product Style
Towable Generator
Product Length
203.9 Inches
Product Width
75.7 Inches
Product Height
94.8 Inches
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Grade
Style
Run Watts
191,000
Rated Watts
Voltage
Voltage Selector Switch
Fuel
Engine
John Deere
Grade
Professional
Style
Tow-Behind
Run Watts
191,000
Voltage
Voltage Selector Switch
Fuel
Diesel
Engine
John Deere
Features
Features
  • Clarke Power Generation Industrial Mobile/Prime Generators
  • Manufactured in Greensboro, North Carolina, USA.
  • 6.8L John Deere PowerTech Plus™ Industrial Diesel Engine (6068HF485)
  • Reliable performance & fuel economy; EPA Tier 3 & CARB Certified
  • 253-Gallon Skid-Base Mounted Fuel Tank w/ Low-Fuel Shutdown
  • Provides a runtime of up to 36 hours & very balanced lifting
  • Racor-style fuel/water separator & fine micron secondary fuel filter
  • Leroy Somer Alternator w/ AREP Brushless Excitation (<5% THD)
  • Industry leading motor starting kVA & 300% overload capability
  • 3-Position Voltage Selector Switch w/ Operation Lock
  • Single Phase 120/139/240/277V & 3-Phase 208/240/416/480V
  • Digital Genset Controller w/ LCD Display
  • Easy to read fault codes w/ # & text explanations
  • Remote Auto Start/Stop (2-Wire, Closed Contact Logic)
  • Allows for connection to auto transfer switch or remote starting device
  • Tandem-Axle Trailer w/ 3" Pintle Hitch, Wheel Chocks & Jack Stand
  • 15" Wheels, torsion suspension, electric brakes & EZ Lube hubs
  • Steel Sound Attenuated Enclosure (69dB(A) @ 23' 100% Load)
  • Wide opening side access doors & center-point lifting eye
  • 1-Year / 2000 Hour Limited Warranty (See Spec Sheet)
Specifications
Plugs
NEMA 5-20R (GFCI)
NEMA 5-20R (GFCI)
CS6369 (50-Amp Twistlock)
CS6369 (50-Amp Twistlock)
CS6369 (50-Amp Twistlock)
Engine
Engine Brand
John Deere
Starting System
12-Volt Key Start
CC
6800 CC
Consumer Engine Warranty
1 Year
Commercial Engine Warranty
1 Year
Engine RPM
1800 RPM
Product Specs
Voltage
Voltage Selector Switch
Frequency
60 Hertz
Alternator
Brushless
Auto Voltage Regulation
Yes
Rated Watts
191000 Watts
Fuel Type
Diesel
Portability Kit
Pneumatic Wheels
Tank Size
253.7 Gallons
Run Time @ 50% Load
36 Hours
Fuel Gauge
Yes
Decibel Rating @ 7m ? Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
69 dbA
Hour Meter
Yes
Voltage Meter
Yes
Lifting Eye
Yes
Battery
Not Included
Grade Type
Professional
Plugs
NEMA 5-20R - GFCI
2
CS6369 - 50-Amp Twistlock
3
Overview
Made in USA
Yes
Weight
7717 Pounds
Product Style
Towable Generator
Product Length
203.9 Inches
Product Width
75.7 Inches
Product Height
94.8 Inches
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Specs
+−
Specifications
Plugs
NEMA 5-20R (GFCI)
NEMA 5-20R (GFCI)
CS6369 (50-Amp Twistlock)
CS6369 (50-Amp Twistlock)
CS6369 (50-Amp Twistlock)
Engine
Engine Brand
John Deere
Starting System
12-Volt Key Start
CC
6800 CC
Consumer Engine Warranty
1 Year
Commercial Engine Warranty
1 Year
Engine RPM
1800 RPM
Product Specs
Voltage
Voltage Selector Switch
Frequency
60 Hertz
Alternator
Brushless
Auto Voltage Regulation
Yes
Rated Watts
191000 Watts
Fuel Type
Diesel
Portability Kit
Pneumatic Wheels
Tank Size
253.7 Gallons
Run Time @ 50% Load
36 Hours
Fuel Gauge
Yes
Decibel Rating @ 7m ? Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
69 dbA
Hour Meter
Yes
Voltage Meter
Yes
Lifting Eye
Yes
Battery
Not Included
Grade Type
Professional
Plugs
NEMA 5-20R - GFCI
2
CS6369 - 50-Amp Twistlock
3
Overview
Made in USA
Yes
Weight
7717 Pounds
Product Style
Towable Generator
Product Length
203.9 Inches
Product Width
75.7 Inches
Product Height
94.8 Inches
Consumer Warranty
1 Year
Commercial Warranty
1 Year
