Champion 46596 - 3500 Watt Portable Generator w/ RV Outlet (49-State)

Champion 46596 - 3500 Watt Portable Generator w/ RV Outlet (49-State)
Model: 46596
(Based on expert analysis, manufacturer ratings and customer reviews)
4.8 out of 54.8 out of 54.8 out of 54.8 out of 54.8 out of 5
Number of Reviews (16)
Write A Review
Product Discontinued
Sorry, this product is no longer available.
Try This Instead
Discontinued

(as of 07:12 CST - Details)Sales Tax Extra $335.99Visit Site
Sales Tax Extra $357.57Visit Site
Discontinued
Sorry, this product is no longer available
Free Shipping
Free Shipping
*We currently CANNOT ship this product to California or any destination outside of the United States
Share
  • Product Description
  • 16
    Reviews
  • 1
    Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Grade
Style
Run Watts
3,500
Rated Watts
Surge Watts
4,000
Starting Watts
Fuel
Engine
Grade
Recreational
Style
Portable
Run Watts
3,500
Surge Watts
4,000 Starting Watts
Fuel
Gasoline
Engine
Champion


Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."

Features
Features
  • Champion Power Equipment 3500 Watt Portable Generator
  • Ideal for RV's, camping, hunting and traveling
  • 196cc Champion OHV 4-Stroke Engine
  • Cast iron sleeve provides extended engine life
  • Low-Oil Shutdown
  • Prevents damage to the generator during operation
  • Circuit Breaker Protection
  • Helps prevent overload to generator
  • 4-Gallon Fuel Tank w/ Fuel Gauge
  • Provides up to 12 hours of runtime @ 1/2 load
  • RV Ready - TT-30R Outlet
  • Power your RV without the need of an extra adapter
  • 1" Full Tubular Wrap-Around Frame
  • Steel frame protects the generator on all sides
  • USDA-Approveed Spark Arrestor
  • Provides added safety when beeing used in dry areas
  • Engine Oil NOT Included
  • NON-CARB Compliant - Not Sold In CA
  • 3-Year Warranty
Specifications
Plugs
NEMA L5-30R
RV Ready 30-Amp
NEMA 5-20R Single (Wall-Type)
Engine
Engine Brand
Champion
Starting System
Recoil Start
CC
196 CC
Consumer Engine Warranty
3 Years
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
Cast Iron Sleeve
Yes
Product Specs
Voltage
120 Single-Phase
Frequency
60 Hertz
Surge Watts
4000 Watts
Rated Watts
3500 Watts
Fuel Type
Gasoline
Rated Amps
29 Amps
Portability Kit
Sold Separately
Tank Size
4 Gallons
Run Time @ 50% Load
12 Hours
Fuel Tank Material
Metal
Fuel Gauge
Yes
Decibel Rating @ 7m Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
Not Measured by Manufacturer
Idle Control
No
Hour Meter
No
Voltage Meter
Yes
Lifting Eye
No
Grade Type
Recreational
Plugs
NEMA 5-20R - Single - Wall-Type
1
NEMA L5-30R
1
RV Ready 30-Amp
1
Overview
Made in USA
No
Weight
97 Pounds
Product Style
Portable Generator
Product Length
23.2 Inches
Product Width
17.8 Inches
Product Height
17.8 Inches
Consumer Warranty
3 Years
UPC
896682465967
Grade
Style
Run Watts
3,500
Rated Watts
Surge Watts
4,000
Starting Watts
Fuel
Engine
Grade
Recreational
Style
Portable
Run Watts
3,500
Surge Watts
4,000 Starting Watts
Fuel
Gasoline
Engine
Champion


Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."

Features
Features
  • Champion Power Equipment 3500 Watt Portable Generator
  • Ideal for RV's, camping, hunting and traveling
  • 196cc Champion OHV 4-Stroke Engine
  • Cast iron sleeve provides extended engine life
  • Low-Oil Shutdown
  • Prevents damage to the generator during operation
  • Circuit Breaker Protection
  • Helps prevent overload to generator
  • 4-Gallon Fuel Tank w/ Fuel Gauge
  • Provides up to 12 hours of runtime @ 1/2 load
  • RV Ready - TT-30R Outlet
  • Power your RV without the need of an extra adapter
  • 1" Full Tubular Wrap-Around Frame
  • Steel frame protects the generator on all sides
  • USDA-Approveed Spark Arrestor
  • Provides added safety when beeing used in dry areas
  • Engine Oil NOT Included
  • NON-CARB Compliant - Not Sold In CA
  • 3-Year Warranty
Specifications
Plugs
NEMA L5-30R
RV Ready 30-Amp
NEMA 5-20R Single (Wall-Type)
Engine
Engine Brand
Champion
Starting System
Recoil Start
CC
196 CC
Consumer Engine Warranty
3 Years
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
Cast Iron Sleeve
Yes
Product Specs
Voltage
120 Single-Phase
Frequency
60 Hertz
Surge Watts
4000 Watts
Rated Watts
3500 Watts
Fuel Type
Gasoline
Rated Amps
29 Amps
Portability Kit
Sold Separately
Tank Size
4 Gallons
Run Time @ 50% Load
12 Hours
Fuel Tank Material
Metal
Fuel Gauge
Yes
Decibel Rating @ 7m Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
Not Measured by Manufacturer
Idle Control
No
Hour Meter
No
Voltage Meter
Yes
Lifting Eye
No
Grade Type
Recreational
Plugs
NEMA 5-20R - Single - Wall-Type
1
NEMA L5-30R
1
RV Ready 30-Amp
1
Overview
Made in USA
No
Weight
97 Pounds
Product Style
Portable Generator
Product Length
23.2 Inches
Product Width
17.8 Inches
Product Height
17.8 Inches
Consumer Warranty
3 Years
UPC
896682465967
Product Specs
+
Specifications
Plugs
NEMA L5-30R
RV Ready 30-Amp
NEMA 5-20R Single (Wall-Type)
Engine
Engine Brand
Champion
Starting System
Recoil Start
CC
196 CC
Consumer Engine Warranty
3 Years
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
Cast Iron Sleeve
Yes
Product Specs
Voltage
120 Single-Phase
Frequency
60 Hertz
Surge Watts
4000 Watts
Rated Watts
3500 Watts
Fuel Type
Gasoline
Rated Amps
29 Amps
Portability Kit
Sold Separately
Tank Size
4 Gallons
Run Time @ 50% Load
12 Hours
Fuel Tank Material
Metal
Fuel Gauge
Yes
Decibel Rating @ 7m Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
Not Measured by Manufacturer
Idle Control
No
Hour Meter
No
Voltage Meter
Yes
Lifting Eye
No
Grade Type
Recreational
Plugs
NEMA 5-20R - Single - Wall-Type
1
NEMA L5-30R
1
RV Ready 30-Amp
1
Overview
Made in USA
No
Weight
97 Pounds
Product Style
Portable Generator
Product Length
23.2 Inches
Product Width
17.8 Inches
Product Height
17.8 Inches
Consumer Warranty
3 Years
UPC
896682465967
Reviews
(16)
+
Champion 46596 Reviews & Ratings
100% of Reviewers Recommend This Product
Product Q&A
(1)
+
Search Product Q&A's Answered by Jim, the Portable Generator Expert
icon-social-fb1
+
What the noise level on the
Corey Lightner
from Virginia
June 28, 2016
Answer
Champion does not test the sound level of its portable generators because there is no industry standard for this measurement, and any results could be misleading. The noise levels of our generators are comparable to many portable generators on the market.

If you have any questions please let us know.
