Champion 100812 - 5000 Watt Portable Generator
Champion 100812 - 5000 Watt Portable Generator
+
Share This Product
-
Product Description
-
Reviews
-
Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Grade
Style
Run Watts
5,000
Rated Watts
Surge Watts
6,250
Starting Watts
Fuel
Engine
Grade
Emergency
Style
Portable
Run Watts
5,000
Surge Watts
6,250 Starting Watts
Fuel
Gasoline
Engine
Champion
Features
Features
- Champion Power Equipment 5000 Watt Portable Generator
- Provides dependable power for home, recreation or emergencies
- 292cc Champion OHV 4-Stroke Engine
- Cast iron sleeve provides extended engine life
- Low-Oil Shutdown
- Provides added protection to extend the life of the generator
- Intelligauge™ Digital Display
- Easily monitor your voltage, frequency & operating hours
- Circuit Breaker Protection
- Helps prevent overload to generator
- Large 5.7-Gallon Extended Run Fuel Tank
- Provides up to 9 hours of runtime at 50% load
- Full Tubular Wrap-Around Frame
- Heavy-duty steel frame protects the generator on all sides
- Mobility Kit w/ Folding Handle & 8" Never-Flat Wheels
- Makes transporting and positioning as simple as possible
- CARB Compliant - For Use In All 50 States
- 3-Year Limited Warranty
Specifications
Plugs
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Auto Voltage Regulation
Yes
Rated Watts
5000 Watts
Surge Watts
6250 Watts
Fuel Type
Gasoline
Rated Amps
21 Amps
Portability Kit
Never Flat Wheels
Tank Size
5.7 Gallons
Run Time @ 50% Load
9 Hours
Fuel Tank Material
Metal
Fuel Gauge
No
Decibel Rating @ 7m
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
Not Measured by Manufacturer
Idle Control
No
Hour Meter
Yes
Voltage Meter
Yes
Lifting Eye
No
Grade Type
Emergency
Engine
Engine Brand
Champion
Starting System
Recoil Start
CC
292 CC
Consumer Engine Warranty
2 Years
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
Cast Iron Sleeve
Yes
Overview
Assembly Required
Yes
Weight
152 Pounds
Made in USA
No
Consumer Warranty
2 Years
Product Style
Portable Generator
Product Length
30.1 Inches
Product Width
25.2 Inches
Product Height
25.7 Inches
UPC
817198023052
Plugs
NEMA 5-20R - GFCI
2
NEMA L14-30R
1
Grade
Style
Run Watts
5,000
Rated Watts
Surge Watts
6,250
Starting Watts
Fuel
Engine
Grade
Emergency
Style
Portable
Run Watts
5,000
Surge Watts
6,250 Starting Watts
Fuel
Gasoline
Engine
Champion
Features
Features
- Champion Power Equipment 5000 Watt Portable Generator
- Provides dependable power for home, recreation or emergencies
- 292cc Champion OHV 4-Stroke Engine
- Cast iron sleeve provides extended engine life
- Low-Oil Shutdown
- Provides added protection to extend the life of the generator
- Intelligauge™ Digital Display
- Easily monitor your voltage, frequency & operating hours
- Circuit Breaker Protection
- Helps prevent overload to generator
- Large 5.7-Gallon Extended Run Fuel Tank
- Provides up to 9 hours of runtime at 50% load
- Full Tubular Wrap-Around Frame
- Heavy-duty steel frame protects the generator on all sides
- Mobility Kit w/ Folding Handle & 8" Never-Flat Wheels
- Makes transporting and positioning as simple as possible
- CARB Compliant - For Use In All 50 States
- 3-Year Limited Warranty
Specifications
Plugs
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Auto Voltage Regulation
Yes
Rated Watts
5000 Watts
Surge Watts
6250 Watts
Fuel Type
Gasoline
Rated Amps
21 Amps
Portability Kit
Never Flat Wheels
Tank Size
5.7 Gallons
Run Time @ 50% Load
9 Hours
Fuel Tank Material
Metal
Fuel Gauge
No
Decibel Rating @ 7m
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
Not Measured by Manufacturer
Idle Control
No
Hour Meter
Yes
Voltage Meter
Yes
Lifting Eye
No
Grade Type
Emergency
Engine
Engine Brand
Champion
Starting System
Recoil Start
CC
292 CC
Consumer Engine Warranty
2 Years
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
Cast Iron Sleeve
Yes
Overview
Assembly Required
Yes
Weight
152 Pounds
Made in USA
No
Consumer Warranty
2 Years
Product Style
Portable Generator
Product Length
30.1 Inches
Product Width
25.2 Inches
Product Height
25.7 Inches
UPC
817198023052
Plugs
NEMA 5-20R - GFCI
2
NEMA L14-30R
1
Product Specs
+−
Specifications
Plugs
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Auto Voltage Regulation
Yes
Rated Watts
5000 Watts
Surge Watts
6250 Watts
Fuel Type
Gasoline
Rated Amps
21 Amps
Portability Kit
Never Flat Wheels
Tank Size
5.7 Gallons
Run Time @ 50% Load
9 Hours
Fuel Tank Material
Metal
Fuel Gauge
No
Decibel Rating @ 7m
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
Not Measured by Manufacturer
Idle Control
No
Hour Meter
Yes
Voltage Meter
Yes
Lifting Eye
No
Grade Type
Emergency
Engine
Engine Brand
Champion
Starting System
Recoil Start
CC
292 CC
Consumer Engine Warranty
2 Years
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
Cast Iron Sleeve
Yes
Overview
Assembly Required
Yes
Weight
152 Pounds
Made in USA
No
Consumer Warranty
2 Years
Product Style
Portable Generator
Product Length
30.1 Inches
Product Width
25.2 Inches
Product Height
25.7 Inches
UPC
817198023052
Plugs
NEMA 5-20R - GFCI
2
NEMA L14-30R
1
