Reliance Controls 200-Amp Indoor Generator-Ready Load Center
Reliance Controls 200-Amp Indoor Generator-Ready Load Center
+
Share This Product
-
Product Description
-
1Reviews
-
3Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Features
Features
- Reliance Panel/Link®
- Perfect for new construction and/or renovation
- Hardwire to your generator or power inlet box
- This load center replaces your house's standard panel
Specifications
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
12500 Watts
Rated Amps
200 Amps
Enclosure
NEMA 1R
Number of Circuit Breakers
36
Max Utility Input
200 Amps
Max Generator Input
50 Amps
Maximum Wattage
12500 Watts
UL Listed
Yes
Overview
Weight
46 Pounds
Made in USA
Yes
Consumer Warranty
2 Years
Product Length
39 Inches
Product Width
14.38 Inches
Product Height
3.94 Inches
UPC
815181015626
Features
Features
- Reliance Panel/Link®
- Perfect for new construction and/or renovation
- Hardwire to your generator or power inlet box
- This load center replaces your house's standard panel
Specifications
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
12500 Watts
Rated Amps
200 Amps
Enclosure
NEMA 1R
Number of Circuit Breakers
36
Max Utility Input
200 Amps
Max Generator Input
50 Amps
Maximum Wattage
12500 Watts
UL Listed
Yes
Overview
Weight
46 Pounds
Made in USA
Yes
Consumer Warranty
2 Years
Product Length
39 Inches
Product Width
14.38 Inches
Product Height
3.94 Inches
UPC
815181015626
Product Specs
+−
Specifications
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
12500 Watts
Rated Amps
200 Amps
Enclosure
NEMA 1R
Number of Circuit Breakers
36
Max Utility Input
200 Amps
Max Generator Input
50 Amps
Maximum Wattage
12500 Watts
UL Listed
Yes
Overview
Weight
46 Pounds
Made in USA
Yes
Consumer Warranty
2 Years
Product Length
39 Inches
Product Width
14.38 Inches
Product Height
3.94 Inches
UPC
815181015626
Product Q&A
(3)
+−
Search Product Q&A's
Answered by Jared, the Generator Expert
+−
IF THE MAIN BREAKER FAILS, DO YOU HAVE REPLACEMENTS AND APPROXIMATELY AT WHAT COST?.......IS IT SPECIFICALLY A RELIANCE CONTROL MANUFACTURED TYPE?.......................THANKS TOM
TOM ANDREASSEN
from New York
October 16, 2013
Answer
Thank you for your interest in Electric Generators Direct!
We do not currently carry any circuit breakers for purchase. The TTV2005D panel can be fitted with a wide range of breakers, each tested and approved to meet UL standards. These are not specific to Reliance Controls and can be purchased from any electrical supplier, or your local hardware store. This applies to the interlocked main breaker as well.
Compatible Circuit Breakers;
SIEMENS TYPES QP, QT, QPH, HQP, QPF, QPHF, QFP, QE, QEH
SQUARE D: SERIES HOM (100A Maximum)
CH/WESTINGHOUSE: SERIES BD, BR, BQ, GFC (All 100A Maximum)
MURRAY: TYPE MP
We do not currently carry any circuit breakers for purchase. The TTV2005D panel can be fitted with a wide range of breakers, each tested and approved to meet UL standards. These are not specific to Reliance Controls and can be purchased from any electrical supplier, or your local hardware store. This applies to the interlocked main breaker as well.
Compatible Circuit Breakers;
SIEMENS TYPES QP, QT, QPH, HQP, QPF, QPHF, QFP, QE, QEH
SQUARE D: SERIES HOM (100A Maximum)
CH/WESTINGHOUSE: SERIES BD, BR, BQ, GFC (All 100A Maximum)
MURRAY: TYPE MP
Was this answer helpful?
Yes
0
No
0
+−
Can you use double breakers to fit more than 36 circuits?
Dennis
from New York
October 06, 2013
Answer
Thank you for your inquiry!
The Reliance Controls, TTV2005D is designed to support up to 36 standard single-pole breakers. Through the use of 2-pole and/or tandem breakers, this number can vary. Please refer to the manufacturer's specifications for a list of compatible circuit breakers.
The Reliance Controls, TTV2005D is designed to support up to 36 standard single-pole breakers. Through the use of 2-pole and/or tandem breakers, this number can vary. Please refer to the manufacturer's specifications for a list of compatible circuit breakers.
Was this answer helpful?
Yes
0
No
0
+−
What circuit breakers do I use for the branch circuits?
Mike
from Iowa
February 08, 2011
Answer
Reliance Controls transfer panels are UL listed for a number of interchangeable breakers (see label on the inside cover of the transfer panel). If the main panel has this type of breaker, relocate the selected branch circuit breakers to the transfer panel. If the breakers cannot be moved, other breakers of the same ampacity must be installed in the transfer panel.
THE FOLLOWING CIRCUIT BREAKERS ARE UL LISTED FOR USE WITH ALL TR, TT, T1 AND T2 SERIES RELIANCE CONTROLS TRANSFER PANELS:
SIEMENS TYPES QP, QT, QPH, HQP, QPF, QPHF, QFP, QE, QEH
SQUARE D: SERIES HOM (100A Maximum)
CH/WESTINGHOUSE: SERIES BD, BR, BQ, GFC (All 100A Maximum)
MURRAY: TYPE MP
THE FOLLOWING CIRCUIT BREAKERS ARE UL LISTED FOR USE WITH ALL TR, TT, T1 AND T2 SERIES RELIANCE CONTROLS TRANSFER PANELS:
SIEMENS TYPES QP, QT, QPH, HQP, QPF, QPHF, QFP, QE, QEH
SQUARE D: SERIES HOM (100A Maximum)
CH/WESTINGHOUSE: SERIES BD, BR, BQ, GFC (All 100A Maximum)
MURRAY: TYPE MP
Was this answer helpful?
Yes
1
No
0
