Generac Mobile 1.4kW Towable Diesel LED Light Towner w/ 2.4kW Export Power & Manual Winch
Model:
MLTS-4
+
Share This Product
Features
Grade
Style
Tow-Behind
Run Watts
3,800 Rated Watts
Voltage
120 Single-Phase
Fuel
Diesel
Engine
Mitsubishi
- Generac Mobile MLTS-4 - 1.4kW Towable Diesel Light Tower w/ Export Power
- Smart, Simple, Small footprint for a wide variety of applications
- 2.4kW Export Power (20A 120V)
- Ideal for applications that require lights and power
- (4) x 390W (47K/188K Lumens) LED Light Fixtures
- IP68 LED Modules with 50,000-hour life
- Aluminum / Poly construction housing and cabinet mounted LED drivers
- 23-Foot, 5-Section Vertical Mast w/ Manual Winch
- 359° Ground rotational mast with mast fully extended
- Dual handle manual winch w/ brake system for easier and safer deployment
- Distinctive angle fixture mount for common light distribution
- .65L Mitsubishi® L2E Liquid Cooled Diesel Engine (EPA Tier 4 Final)
- Fuel efficient design runs at 1800 RPM for extended engine life
- User-friendly, low maintenance, 1000-Hour service interval
- 39.9-Gallon Polyethylene Internal Fuel Tank
- Provides up to 162 hours of run time with all 4-lights On
- Marathon Electric® Brushless Alternator
- Long life & low maintenance design
- Improved Engine Control System
- External, illuminated control panel with sealed switches
- Digital hour meter; Automatic low oil pressure/high temp. shutdown
- (1) Switch controls all light fixtures
- Corrosion-Proof Poly Shell
- Rear flip hood compartment provides unobstructed service access
- Tubular Steel Trailer w/ (3) 1200 lb. Tube & Sleeve Leveling Jacks
- DOT-approved LED tail, side, brake, and directional lights
- 13" ST175/80D13 - 6 ply wheel/tire; 47" track width
- 2" Ball hitch and safety chains with spring loaded safety hooks
- Includes Starting Battery
- CUSTOMERS MUST UNLOAD FROM FREIGHT CARRIER
- 2-Year / 2,000 Hour Limited Warranty
California residents see
Warning: This product can expose you to chemicals including Diesel engine exhaust which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov
Specifications
Plug Types
![NEMA 5-20R (Wall-Type)](/images/plug_image7.jpg)
MLTS-4
![specs product image PID-113734](/products-image/150/mlts-4_113734_1000_3606b8bab1b65388f297f231c38f95e8.jpg)
General Information
Product Category
Light Tower
Overview
Product Category
Light Tower
Weight
1110 Pounds
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
118 Inches
Product Width
57 Inches
Product Height
101 Inches
Product Specs
Voltage
120 Single-Phase
Frequency
60 Hertz
Alternator
Brushless
Rated Watts
3800 Watts
Fuel Type
Diesel
Tank Size
39.9 Gallons
Decibel Rating @ 7m
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
67
Lifting Eye
Yes
Battery
Included
Enclosure
Composite
Fuel Consumption
.25 gallons/hr
Engine
Engine Brand
Mitsubishi
Starting System
12-Volt Key Start
CC
635 CC
Consumer Engine Warranty
2 Years
Commercial Engine Warranty
2 Years
Engine RPM
1800 RPM
Low Oil Alert/Shutdown
Yes
Plugs
NEMA 5-20R - Wall-Type
1
