Generac Mobile 6kW Narrow Body Towable Diesel Vertical Mast LED Light Tower w/ AVR, Manual Winch & Power Zone Controller

Name: Generac Mobile 6kW Narrow Body Towable Diesel Vertical Mast LED Light Tower w/ AVR, Manual Winch & Power Zone Controller
Brand: Generac
SKU: 113748
Price: 21999.00 USD
Availability: OutOfStock

Model:

MLT4060MVD-STD3

Write A Review

Product Discontinued

Sorry, this product is no longer available.

Continue Shopping With These Categories

Shop All Portable Light Towers

Shop Generac Light Towers

Generac Mobile 6kW Narrow Body Towable Diesel Vertical Mast LED Light Tower w/ AVR, Manual Winch & Power Zone Controller

Model: MLT4060MVD-STD3

Product Discontinued

Features

Specifications

Reviews

How-To Articles

Manuals

Features

Grade

Style

Tow-Behind

Run Watts

6,000 Rated Watts

Voltage

120/240 Single-Phase

Fuel

Diesel

Engine

Mitsubishi

Generac MLT4060MVD-STD3 6kW Towable Diesel LED Light Tower (Electric Winch)
Powerful, compact illumination for a variety of applications
(4) x 320W (47K/188K Lumens) LED Light Fixtures
IP68 LED Modules with 50,000-hour life
Aluminum / Poly construction housing and cabinet mounted LED drivers
23-Foot, 5-Section Vertical Mast w/ Electric Winch
359° Ground rotational mast with mast fully extended
Allows for quick setup, Raises mast in 15 seconds
Distinctive angle fixture mount for common light distribution
.95L Mitsubishi® L3E ECOSpeed Liquid Cooled Diesel Engine (EPA Tier 4 Final)
User-friendly, low maintenance, 1000-Hour service interval
Provides greater fuel efficiency by reducing engine speed based on demand
104-Gallon Polyethylene Internal Fuel Tank
Allows for run times up to 530 hours with LED lighting load
120/240V - 50/25A Marathon Electric® Brushless Alternator
Robust design provides up to 6 kW of standby output
Long life & low maintenance while providing +/- 1% voltage reg. (AVR)
Power Zone® Autolight Controller
Automated dusk to dawn or 7-day scheduler operation
Improved Engine Control System
Back-lit LCD display with programmable service timers and one-touch starting
Digital hour meter; Automatic low oil pressure/high temp. shutdown
(1) 120V 20A GFCI Duplex Outlet & (1) 120/240V 30A (L14-30R) Twistlock Outlet
Individually breakered for added safety during operation
Corrosion-Proof Aluminum Enclosure
Central lifting point and fork pockets
Sound rating: 63 db(A) @ 23'
Tubular Steel Trailer w/ (4) 2000 lb. Tube & Sleeve Leveling Jacks
DOT-approved LED tail, side, brake & directional lights; 15" 6-ply tires
2" Ball hitch and safety chains with spring loaded safety hooks
Includes Starting Battery
CUSTOMERS MUST UNLOAD FROM FREIGHT CARRIER
2-Year / 2,000 Hour Limited Warranty
10,000 Hour Parts Warranty On LED Modules & Drivers

California residents see

Warning: This product can expose you to chemicals including Diesel engine exhaust which is known to the State of California to cause Cancer.

For more information go to: www.p65Warnings.ca.gov

Specifications

Plug Types

MLT4060MVD-STD3

Overview

Weight

1694 Pounds

Consumer Warranty

2 Years

Commercial Warranty

2 Years

Product Length

124.8 Inches

Product Width

68.4 Inches

Product Height

100.8 Inches

Product Specs

Voltage

120/240 Single-Phase

Frequency

60 Hertz

Alternator

Brushless

Auto Voltage Regulation

Yes

Rated Watts

6000 Watts

Fuel Type

Diesel

Tank Size

104 Gallons

Fuel Tank Material

Plastic Resin

Decibel Rating @ 7m

Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.

Idle Control

Yes

Hour Meter

Yes

Lifting Eye

Yes

Battery

Included

Enclosure

Aluminum

Fuel Consumption

0.195 gallons/hr
