Winco DR20 - 20kW Automatic Diesel Generator

Winco DR20 - 20kW Automatic Diesel Generator
Model: DR20
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Discontinued
Sorry, this product is no longer available
Free Freight
Free Freight
*We currently CANNOT ship this product to Alaska, California, Hawaii or any destination outside of the United States
Share
  • Product Description
  • Reviews
  • 1
    Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Grade
Style
Run Watts
20,000
Rated Watts
Surge Watts
20,000
Starting Watts
Fuel
Engine
Isuzu
Grade
Emergency
Style
Standby (Liquid Cooled)
Run Watts
20,000
Surge Watts
20,000 Starting Watts
Fuel
Diesel
Engine
Isuzu
Features
Features
  • Liquid-Cooled Diesel Standby Generator
  • Designed for long life
  • 2.2L Isuzu Diesel Engine
  • Provides long life, high performance, and great fuel efficiency
  • Large 32-Gallon Single-Wall Composite Fuel Tank
  • Provides up to 28.8 hours of run time @ 1/2 load
  • Remote Starting Capability
  • Can be used w/ automatic transfer switch for standby applications
  • Deep Sea DSE 7310 Digital Genset Controller
  • Automatic safety shutdowns provide added safety
  • Monitors all aspects of your genset & Event fault log recording
  • Configurable (7) Inputs & (8) Outputs
  • Glow plugs & starter solenoid controls
  • Electrician Friendly Design
  • Single cover connection points & pre-installed block heater
  • Powder Coated Steel Enclosure & Welded Steel Base
  • 1
  • Automatic Transfer Switch Not Included & Sold Separately
  • Starting Battery BCI 24 650 CCA Not Included
  • Warranty: 1-Year/1000 Hours Generator & 3-Year/3000 Hr Engine
Specifications
Plugs
NEMA 5-20R (GFCI)
NEMA 5-20R (GFCI)
CS6369 (50-Amp Twistlock)
CS6369 (50-Amp Twistlock)
Engine
Engine Brand
Isuzu
Starting System
12v Auto Start
CC
2200 CC
Consumer Engine Warranty
3 Years
Commercial Engine Warranty
3 Years
Engine RPM
1800 RPM
Low Oil Alert/Shutdown
Yes
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Surge Watts
20000 Watts
Rated Watts
20000 Watts
Fuel Type
Diesel
Diesel Fuel Consumption @ 50% Load
1.75 gallons/hr
Rated Amps
83 Amps
Run Time @ 50% Load
28.8 Hours
Decibel Rating @ 7m
69 dbA
Battery
Not Included (650 CCA)
Cooling System
Liquid Cooled
UL Listed
No
Grade Type
Emergency
Plugs
NEMA 5-20R - GFCI
2
CS6369 - 50-Amp Twistlock
2
Overview
Weight
1635 Pounds
Product Style
Standby Generator
Product Length
63 Inches
Product Width
34 Inches
Product Height
49.75 Inches
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Grade
Style
Run Watts
20,000
Rated Watts
Surge Watts
20,000
Starting Watts
Fuel
Engine
Isuzu
Grade
Emergency
Style
Standby (Liquid Cooled)
Run Watts
20,000
Surge Watts
20,000 Starting Watts
Fuel
Diesel
Engine
Isuzu
Features
Features
  • Liquid-Cooled Diesel Standby Generator
  • Designed for long life
  • 2.2L Isuzu Diesel Engine
  • Provides long life, high performance, and great fuel efficiency
  • Large 32-Gallon Single-Wall Composite Fuel Tank
  • Provides up to 28.8 hours of run time @ 1/2 load
  • Remote Starting Capability
  • Can be used w/ automatic transfer switch for standby applications
  • Deep Sea DSE 7310 Digital Genset Controller
  • Automatic safety shutdowns provide added safety
  • Monitors all aspects of your genset & Event fault log recording
  • Configurable (7) Inputs & (8) Outputs
  • Glow plugs & starter solenoid controls
  • Electrician Friendly Design
  • Single cover connection points & pre-installed block heater
  • Powder Coated Steel Enclosure & Welded Steel Base
  • 1
  • Automatic Transfer Switch Not Included & Sold Separately
  • Starting Battery BCI 24 650 CCA Not Included
  • Warranty: 1-Year/1000 Hours Generator & 3-Year/3000 Hr Engine
Specifications
Plugs
NEMA 5-20R (GFCI)
NEMA 5-20R (GFCI)
CS6369 (50-Amp Twistlock)
CS6369 (50-Amp Twistlock)
Engine
Engine Brand
Isuzu
Starting System
12v Auto Start
CC
2200 CC
Consumer Engine Warranty
3 Years
Commercial Engine Warranty
3 Years
Engine RPM
1800 RPM
Low Oil Alert/Shutdown
Yes
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Surge Watts
20000 Watts
Rated Watts
20000 Watts
Fuel Type
Diesel
Diesel Fuel Consumption @ 50% Load
1.75 gallons/hr
Rated Amps
83 Amps
Run Time @ 50% Load
28.8 Hours
Decibel Rating @ 7m
69 dbA
Battery
Not Included (650 CCA)
Cooling System
Liquid Cooled
UL Listed
No
Grade Type
Emergency
Plugs
NEMA 5-20R - GFCI
2
CS6369 - 50-Amp Twistlock
2
Overview
Weight
1635 Pounds
Product Style
Standby Generator
Product Length
63 Inches
Product Width
34 Inches
Product Height
49.75 Inches
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Specs
+
Specifications
Plugs
NEMA 5-20R (GFCI)
NEMA 5-20R (GFCI)
CS6369 (50-Amp Twistlock)
CS6369 (50-Amp Twistlock)
Engine
Engine Brand
Isuzu
Starting System
12v Auto Start
CC
2200 CC
Consumer Engine Warranty
3 Years
Commercial Engine Warranty
3 Years
Engine RPM
1800 RPM
Low Oil Alert/Shutdown
Yes
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Surge Watts
20000 Watts
Rated Watts
20000 Watts
Fuel Type
Diesel
Diesel Fuel Consumption @ 50% Load
1.75 gallons/hr
Rated Amps
83 Amps
Run Time @ 50% Load
28.8 Hours
Decibel Rating @ 7m
69 dbA
Battery
Not Included (650 CCA)
Cooling System
Liquid Cooled
UL Listed
No
Grade Type
Emergency
Plugs
NEMA 5-20R - GFCI
2
CS6369 - 50-Amp Twistlock
2
Overview
Weight
1635 Pounds
Product Style
Standby Generator
Product Length
63 Inches
Product Width
34 Inches
Product Height
49.75 Inches
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Reviews
+
Be the First to Write a Review
Do you own this product?
Please share your insights with fellow shoppers.
Product Q&A
(1)
+
Search Product Q&A's Answered by Mike, the Generator Expert
icon-social-fb1
+
We are building 5,000 sq ft house in rural Missouri. What type of back up generator gives the most trouble free dependable bang for the buck-diesel or propane?There have been some terrible ice storms here that have left some areas without power for up to 2 weeks. We will mainly be running off grid power so will use the generator only for emergency back up. Then, which one specifically would you recommend?
Jeff
from Missouri
June 26, 2016
Answer
If you plan on being off grid then the only option would be diesel and the Winco would be a good choice. These units can be manually operated at any time and are rated for "Prime Power" which is for off-grid applications.

Prime Power Generators
