Wanco 7.5kW Towable Diesel Standard Laydown Light Tower w/ Kubota D-1105 Engine

Wanco 7.5kW Towable Diesel Standard Laydown Light Tower w/ Kubota D-1105 Engine
Model: WLT-4MK8K
$10,699.00
Factory-Direct
Ships in 3-4 Weeks
Factory items ship direct from the manufacturer.
Shipping times vary.
Free Shipping &
Tax-Free (Except IL)
Factory-Direct
Ships in 3-4 Weeks
Free Freight
Free Freight
*We currently CANNOT ship this product to Alaska, Hawaii or any destination outside of the United States
Share
  • Product Description
  • Reviews
  • Product Q&A
  • Recommended Accessories
  • How-To Articles
Product Description
+
Grade
Style
Run Watts
7,500
Rated Watts
Voltage
120/240 Single-Phase
Fuel
Engine
Kubota
Grade
Professional
Style
Tow-Behind
Run Watts
7,500
Voltage
120/240 Single-Phase
Fuel
Diesel
Engine
Kubota
Features
Features
  • Wanco 7.5kW Diesel Powered Standard Laydown Light Tower
  • State-of-the-art technology to achieve superior illumination
  • 4 x 1000-Watt Metal Halide Lamps
  • High-efficiency light fixtures provide uniform light pattern
  • Each light fixture can be aimed independently without the use of tools
  • 30' Variable-Height Double-Reinforced Telescoping Tower Mast
  • Hand-operated, dual-winch design makes it easy to raise and extend the mast
  • Rotates 360 for optimum lighting at any height
  • 1123cc Liquid-Cooled 3-Cylinder Kubota D-1105 Diesel Engine (Tier 4 Compliant)
  • Fuel efficient design runs at 1800 RPM for long engine life
  • E-TVCS (Three Vortex Combustion System) for cleaner and quite power
  • Glow-plug preheat system for increased service life & better cold-weather starting
  • Automatic Engine Shutdown System
  • For added protection against low oil pressure and high coolant temperature
  • Brushless Alternator
  • For long life and low maintenance while providing <5% THD
  • User-Friendly Control Panel
  • Makes it simple to track elapsed time
  • 30-Gallon Translucent Polyethylene Internal Fuel Tank
  • Instantly view fuel level, eliminating the need for fuel gauge
  • Provides extended run times of 60 to 70 hours
  • Exclusive Hinged Top Panel & Gull-Wing Side Doors
  • Provides easy access to engine, generator & electrical components
  • Lockable, weather-resistant powder-coated steel enclosure
  • Single Axle Trailer
  • Two outriggers & four leveling jacks provide increased stability
  • Combination 2" Ball / 3" Pintle Hitch standard
  • Generator Warranty 2 Years / 2000 Hours - Engine 1 Year
Specifications
Plugs
NEMA 5-20R (GFCI)
Engine
Engine Brand
Kubota
Starting System
12-Volt Button Start
CC
1123 CC
Consumer Engine Warranty
1 Year
Commercial Engine Warranty
1 Year
Engine RPM
1800 RPM
Low Oil Alert/Shutdown
Yes
Cast Iron Sleeve
Yes
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Alternator
Brushless
Rated Watts
7500 Watts
Fuel Type
Diesel
Tank Size
30 Gallons
Fuel Tank Material
Plastic Resin
Decibel Rating @ 7m
71
Hour Meter
Yes
Enclosure
Steel
Battery
Included (550 CCA)
Fuel Consumption
.44 gallons/hr
Cooling System
Liquid Cooled
Grade Type
Professional
Plugs
NEMA 5-20R - GFCI
1
Overview
Made in USA
Yes
Weight
1800 Pounds
Product Style
Light Tower
Product Length
176 Inches
Product Width
47 Inches
Product Height
66 Inches
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Grade
Style
Run Watts
7,500
Rated Watts
Voltage
120/240 Single-Phase
Fuel
Engine
Kubota
Grade
Professional
Style
Tow-Behind
Run Watts
7,500
Voltage
120/240 Single-Phase
Fuel
Diesel
Engine
Kubota
Features
Features
  • Wanco 7.5kW Diesel Powered Standard Laydown Light Tower
  • State-of-the-art technology to achieve superior illumination
  • 4 x 1000-Watt Metal Halide Lamps
  • High-efficiency light fixtures provide uniform light pattern
  • Each light fixture can be aimed independently without the use of tools
  • 30' Variable-Height Double-Reinforced Telescoping Tower Mast
  • Hand-operated, dual-winch design makes it easy to raise and extend the mast
  • Rotates 360 for optimum lighting at any height
  • 1123cc Liquid-Cooled 3-Cylinder Kubota D-1105 Diesel Engine (Tier 4 Compliant)
  • Fuel efficient design runs at 1800 RPM for long engine life
  • E-TVCS (Three Vortex Combustion System) for cleaner and quite power
  • Glow-plug preheat system for increased service life & better cold-weather starting
  • Automatic Engine Shutdown System
  • For added protection against low oil pressure and high coolant temperature
  • Brushless Alternator
  • For long life and low maintenance while providing <5% THD
  • User-Friendly Control Panel
  • Makes it simple to track elapsed time
  • 30-Gallon Translucent Polyethylene Internal Fuel Tank
  • Instantly view fuel level, eliminating the need for fuel gauge
  • Provides extended run times of 60 to 70 hours
  • Exclusive Hinged Top Panel & Gull-Wing Side Doors
  • Provides easy access to engine, generator & electrical components
  • Lockable, weather-resistant powder-coated steel enclosure
  • Single Axle Trailer
  • Two outriggers & four leveling jacks provide increased stability
  • Combination 2" Ball / 3" Pintle Hitch standard
  • Generator Warranty 2 Years / 2000 Hours - Engine 1 Year
Specifications
Plugs
NEMA 5-20R (GFCI)
Engine
Engine Brand
Kubota
Starting System
12-Volt Button Start
CC
1123 CC
Consumer Engine Warranty
1 Year
Commercial Engine Warranty
1 Year
Engine RPM
1800 RPM
Low Oil Alert/Shutdown
Yes
Cast Iron Sleeve
Yes
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Alternator
Brushless
Rated Watts
7500 Watts
Fuel Type
Diesel
Tank Size
30 Gallons
Fuel Tank Material
Plastic Resin
Decibel Rating @ 7m
71
Hour Meter
Yes
Enclosure
Steel
Battery
Included (550 CCA)
Fuel Consumption
.44 gallons/hr
Cooling System
Liquid Cooled
Grade Type
Professional
Plugs
NEMA 5-20R - GFCI
1
Overview
Made in USA
Yes
Weight
1800 Pounds
Product Style
Light Tower
Product Length
176 Inches
Product Width
47 Inches
Product Height
66 Inches
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Specs
+
Specifications
Plugs
NEMA 5-20R (GFCI)
Engine
Engine Brand
Kubota
Starting System
12-Volt Button Start
CC
1123 CC
Consumer Engine Warranty
1 Year
Commercial Engine Warranty
1 Year
Engine RPM
1800 RPM
Low Oil Alert/Shutdown
Yes
Cast Iron Sleeve
Yes
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Alternator
Brushless
Rated Watts
7500 Watts
Fuel Type
Diesel
Tank Size
30 Gallons
Fuel Tank Material
Plastic Resin
Decibel Rating @ 7m
71
Hour Meter
Yes
Enclosure
Steel
Battery
Included (550 CCA)
Fuel Consumption
.44 gallons/hr
Cooling System
Liquid Cooled
Grade Type
Professional
Plugs
NEMA 5-20R - GFCI
1
Overview
Made in USA
Yes
Weight
1800 Pounds
Product Style
Light Tower
Product Length
176 Inches
Product Width
47 Inches
Product Height
66 Inches
Consumer Warranty
2 Years
Commercial Warranty
2 Years
