Generac 200-Amp Automatic Transfer Switch (277/480V)

Generac 200-Amp Automatic Transfer Switch (277/480V)
Our Price
Compare Prices
Shipping Info
Model: RTSN200K3
$1,204.00

Factory-Direct
Ships in 4-6 Weeks
Factory items ship direct from the manufacturer.
Shipping times vary.
Shipping Crate Icon
Free Shipping

Factory-Direct
Ships in 4-6 Weeks
Free Freight
Free Freight
*We currently CANNOT ship this product to Alaska, Hawaii or any destination outside of the United States
Share
  • Product Description
  • Reviews
  • Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Type
Standard
Amp Rating
200
Load Mgmt.
Enclosure
NEMA 3R
Type
Standart
Enclosure
NEMA 3R
Features
Features
  • 3-Phase Automatic Transfer switch
  • Only works with 277/480 3-Phase generators
  • Fully Automatic Operation
  • Standard Installation
  • May require a sub-panel or disconnect for serviceability
  • Larger Applications
  • Nema 3R Aluminum Enclosure
  • For Use With Generac Generators Only
  • Ul Listed 2200
Specifications
Overview
Made in USA
Yes
Weight
105 Pounds
Product Length
48 Inches
Product Width
30 Inches
Product Height
12 Inches
Consumer Warranty
5 Years
UPC
696471112337
Product Specs
Voltage
277/480 Three-Phase
Frequency
60 Hertz
Rated Amps
200 Amps
Enclosure
NEMA 3R
ATS Poles
3 Poles
Transfer Switch Style
Standard Installation
Max Utility Input
200 Amps
Max Generator Input
200 Amps
UL Listed
Yes
Type
Standard
Amp Rating
200
Load Mgmt.
Enclosure
NEMA 3R
Type
Standart
Enclosure
NEMA 3R
Features
Features
  • 3-Phase Automatic Transfer switch
  • Only works with 277/480 3-Phase generators
  • Fully Automatic Operation
  • Standard Installation
  • May require a sub-panel or disconnect for serviceability
  • Larger Applications
  • Nema 3R Aluminum Enclosure
  • For Use With Generac Generators Only
  • Ul Listed 2200
Specifications
Overview
Made in USA
Yes
Weight
105 Pounds
Product Length
48 Inches
Product Width
30 Inches
Product Height
12 Inches
Consumer Warranty
5 Years
UPC
696471112337
Product Specs
Voltage
277/480 Three-Phase
Frequency
60 Hertz
Rated Amps
200 Amps
Enclosure
NEMA 3R
ATS Poles
3 Poles
Transfer Switch Style
Standard Installation
Max Utility Input
200 Amps
Max Generator Input
200 Amps
UL Listed
Yes
Product Specs
+
Specifications
Overview
Made in USA
Yes
Weight
105 Pounds
Product Length
48 Inches
Product Width
30 Inches
Product Height
12 Inches
Consumer Warranty
5 Years
UPC
696471112337
Product Specs
Voltage
277/480 Three-Phase
Frequency
60 Hertz
Rated Amps
200 Amps
Enclosure
NEMA 3R
ATS Poles
3 Poles
Transfer Switch Style
Standard Installation
Max Utility Input
200 Amps
Max Generator Input
200 Amps
UL Listed
Yes
