Generac Mobile 6kW Towable Diesel Vertical Mast LED Light Tower w/ Mitsubishi Engine & Manual Winch

Model:

MLT6SMDS-STD3

Write A Review
$12,999.00
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
This Item Is Built To Order
synchrony card logo
$195 / Month
With our 88 months 7.99% APR*
88 fixed monthly payments required.
Generac Mobile 6kW Towable Diesel Vertical Mast LED Light Tower w/ Mitsubishi Engine & Manual Winch
Generac Mobile 6kW Towable Diesel Vertical Mast LED Light Tower w/ Mitsubishi Engine & Manual Winch
Model: MLT6SMDS-STD3
$12,999.00
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Features

Grade

Style

Tow-Behind

Run Watts

6,000 Rated Watts

Voltage

120/240 Single-Phase

Fuel

Diesel

Engine

Mitsubishi

  • Generac Mobile MLT6SMDS-STD3 - 6kW Towable Diesel Light Tower
  • The newest member of the MLT6 light tower family
  • (4) x 390W (47K/188K Lumens) LED Light Fixtures
  • IP68 LED Modules with 50,000-hour life
  • Aluminum / Poly construction housing and cabinet mounted LED drivers
  • 23-Foot, 5-Section Vertical Mast w/ Manual Winch
  • 359° Ground rotational mast with mast fully extended
  • Dual handle manual winch w/ brake system for easier and safer deployment
  • Distinctive angle fixture mount for common light distribution
  • .95L Mitsubishi® L3E Liquid Cooled Diesel Engine (EPA Tier 4 Final)
  • Fuel efficient design runs at 1800 RPM for extended engine life
  • User-friendly, low maintenance, 1000-Hour service interval
  • 39.9-Gallon Polyethylene Internal Fuel Tank
  • Provides up to 164 hours of run time with all 4-lights On
  • 120/240V - 20/30A Marathon Electric Brushless Alternator
  • Robust design provides up to 6 kW of standby output
  • Long life & low maintenance while providing +/- 6% voltage reg.
  • Improved Engine Control System
  • External, illuminated control panel with sealed switches
  • Digital hour meter; Automatic low oil pressure/high temp. shutdown
  • (1) 120V 20A GFCI Duplex Outlet & (1) 120/240V 30A (L14-30R) Twistlock Outlet
  • Individually breakered for added safety during operation
  • Corrosion-Proof Poly Shell
  • Rear flip hood compartment provides unobstructed service access
  • Tubular Steel Trailer w/ (3) 1200 lb. Tube & Sleeve Leveling Jacks
  • DOT-approved LED tail, side, brake, and directional lights
  • 13" ST175/80D13 - 6 ply wheel/tire; 47" track width
  • 2" Ball hitch and safety chains with spring loaded safety hooks
  • Includes Starting Battery
  • CUSTOMERS MUST UNLOAD FROM FREIGHT CARRIER
  • 2-Year / 2,000 Hour Limited Warranty
California residents see
Warning: This product can expose you to chemicals including Diesel engine exhaust which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov

Specifications

Plug Types
NEMA 5-20R (GFCI)
NEMA L14-30R
MLT6SMDS-STD3
specs product image PID-113735
General Information
Product Category
Light Tower
Overview
Product Category
Light Tower
Weight
1310 Pounds
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
118 Inches
Product Width
57 Inches
Product Height
101 Inches
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Alternator
Brushless
Rated Watts
6000 Watts
Fuel Type
Diesel
Tank Size
39.9 Gallons
Fuel Tank Material
Plastic Resin
Decibel Rating @ 7m Learn More
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
63
Lifting Eye
Yes
Battery
Included
Enclosure
Composite
Fuel Consumption
.243 gallons/hr
Engine
Engine Brand
Mitsubishi
Starting System
12-Volt Key Start
CC
950 CC
Consumer Engine Warranty
2 Years
Commercial Engine Warranty
2 Years
Engine RPM
1800 RPM
Low Oil Alert/Shutdown
Yes
Plugs
NEMA 5-20R - GFCI
1
NEMA L14-30R
1
