Generac MLT6SM-STD2 - 6kW Towable Diesel Vertical Mast Light Tower w/ Mitsubishi Engine & Electric Winch

Model:

MLT6SM-STD2

Write a Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Generac MLT6SM-STD2 - 6kW Towable Diesel Vertical Mast Light Tower w/ Mitsubishi Engine & Electric Winch
Generac MLT6SM-STD2 - 6kW Towable Diesel Vertical Mast Light Tower w/ Mitsubishi Engine & Electric Winch
Model: MLT6SM-STD2
Product Discontinued
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Features

Grade

Professional

Style

Tow-Behind

Run Watts

6,000 Rated Watts

Voltage

120/240 Single-Phase

Fuel

Diesel

Engine

Mitsubishi

  • Generac MLT6SM-STD2 - 6kW Towable Diesel Light Tower (Mitsubishi® / Electric Winch)
  • Designed & engineered for optimum performance & reliability
  • 4 x 1000-Watt Metal Halide Lamps
  • Provides light coverage for up to 7 acres; Individual On/Off switches
  • Oval aluminum reflector w/ tempered glass lens
  • Friction disc mounting for tool less positioning
  • 23-Foot, 5-Section Vertical Mast w/ Electric Winch
  • 359° Ground rotational mast with mast fully extended
  • Distinctive angle fixture mount for common light distribution
  • .95L Mitsubishi® L3E Liquid Cooled Diesel Engine (EPA Tier 4 Final)
  • Fuel efficient design runs at 1800 RPM for extended engine life
  • 43-Gallon Polyethylene Internal Fuel Tank
  • Provides up to 90 hours of run time with all 4-light On
  • 3.5" External fill port for easier access
  • 120/240V - 50/25A Marathon Electric Brushless Alternator
  • Robust design provides up to 6 kW of standby output
  • Long life & low maintenance while providing +/- 6% voltage reg.
  • Improved Engine Control System
  • External, illuminated control panel with sealed switches
  • Digital hour meter; Automatic low oil pressure/high temp. shutdown
  • (1) 120V 20A GFCI Duplex Outlet & (1) 240V 30A (L6-30R) Twistlock Outlet
  • Individually breakered for added safety during operation
  • Corrosion-Proof Poly Shell
  • Rear flip hood compartment provides unobstructed service access
  • Tubular Steel Trailer w/ (3) 1200 lb. Tube & Sleeve Leveling Jacks
  • DOT-approved LED tail, side, brake, and directional lights
  • 13" ST175/80D13 - 6 ply wheel/tire; 47" track width
  • 2" Ball hitch and safety chains with spring loaded safety hooks
  • Includes Starting Battery
  • CUSTOMERS MUST UNLOAD FROM FREIGHT CARRIER
  • 2-Year / 2,000 Hour Limited Warranty
California residents see
Warning: This product can expose you to chemicals including Carbon monoxide which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

Plug Types
NEMA 5-20R (GFCI)
NEMA L6-30R
MLT6SM-STD2
specs product image PID-76314
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Alternator
Brushless
Auto Voltage Regulation
Yes
Rated Watts
6000 Watts
Fuel Type
Diesel
Rated Amps
25 Amps
Tank Size
43.5 Gallons
Fuel Tank Material
Plastic Resin
Idle Control
No
Hour Meter
Yes
Lifting Eye
Yes
Grade Type
Professional
Engine
Engine Brand
Mitsubishi
Starting System
12-Volt Button Start
HP
12.2 HP
CC
950 CC
Engine RPM
1800 RPM
Low Oil Alert/Shutdown
Yes
Overview
Weight
1290 Pounds
Certification
EPA Tier 4
Made in USA
Yes
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
118 Inches
Product Style
Light Tower
Product Width
57 Inches
Product Height
101 Inches
Plugs
NEMA 5-20R - GFCI
1
NEMA L6-30R
1
