Generac Guardian™ 8kW Home Standby Generator

Generac Guardian™ 8kW Home Standby Generator
Share
  • Product Description
  • 7
    Reviews
  • 5
    Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Grade
Style
Run Watts
8,000
Rated Watts
Voltage
120/240 Single-Phase
Fuel
Engine
Grade
Emergency
Style
Standby (Air Cooled)
Run Watts
8,000
Voltage
120/240 Single-Phase
Fuel
LP/Natural Gas
Engine
Generac OHVI
Features
Features
  • Fully Automatic Operation When Paired With Genearc Smart Switch™
  • Generac OHVI Air-Cooled Engine
  • Features plateau honed cylinder walls and plasma-moly rings
  • Full pressure lubrication system w/ 2 year oil change interval
  • Aids in cooling the engine for longer life
  • Operates On Clean Burning, Efficient Natural Gas or LP (Vapor)
  • Skewed Rotor Design For Smooth Output Waveform "Clean Power"
  • Automatic voltage regulator equipped for +/- 1% regulation
  • Evolution™ Digital Controller Monitors & Controls All Functions
  • Provides system status for wireless monitors & Mobile Link™
  • Sound Attenuated Weather Proof Enclosure
  • Attractive styling with lockable access doors
  • Incorporates electrostatically applied epoxy paint technology
  • Sound dampening enclosure limits sound pressure to a low 62dB(A)
  • 12" flexible fuel line and manual included
  • Built-in Battery Charger (Battery Sold Separately)
  • Automatic Transfer Switch - ATS (Sold Separately)
  • Select the ideal ATS & PMM™ modules for load shed capabilities
  • Automatic Operation Only & Listed to UL2200 Standards For Safety
  • 5-Year Limited Warranty & 24/7/365 Customer Care
Specifications
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
8000 Watts
Surge Watts
8000 Watts
Fuel Type
LP/Natural Gas
NG Power Capacity
7000 Watts
LP Power Capacity
8000 Watts
NG Fuel Consumption @ 50% Load
77 ft³/hr
NG Fuel Consumption @ 100% Load
121 ft³/hr
LP Fuel Consumption @ 50% Load
0.94 gallons/hr
LP Fuel Consumption @ 100% Load
1.42 gallons/hr
Rated Amps
33 Amps
Decibel Rating @ 7m Learn More
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
62 dbA
Transfer Switch
Automatic (Not Included)
Battery
Not Included (525 CCA)
Enclosure
Steel
Cooling System
Air Cooled
UL Listed
Yes
Grade Type
Emergency
Engine
Engine Brand
Generac OHVI
CC
410 CC
Consumer Engine Warranty
5 Years
Commercial Engine Warranty
5 Years
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
Overview
Weight
340 Pounds
Made in USA
Yes
Consumer Warranty
5 Years
Commercial Warranty
5 Years
Product Style
Standby Generator
Product Length
48 Inches
Product Width
25 Inches
Product Height
29 Inches
UPC
696471062458
Grade
Style
Run Watts
8,000
Rated Watts
Voltage
120/240 Single-Phase
Fuel
Engine
Grade
Emergency
Style
Standby (Air Cooled)
Run Watts
8,000
Voltage
120/240 Single-Phase
Fuel
LP/Natural Gas
Engine
Generac OHVI
Features
Features
  • Fully Automatic Operation When Paired With Genearc Smart Switch™
  • Generac OHVI Air-Cooled Engine
  • Features plateau honed cylinder walls and plasma-moly rings
  • Full pressure lubrication system w/ 2 year oil change interval
  • Aids in cooling the engine for longer life
  • Operates On Clean Burning, Efficient Natural Gas or LP (Vapor)
  • Skewed Rotor Design For Smooth Output Waveform "Clean Power"
  • Automatic voltage regulator equipped for +/- 1% regulation
  • Evolution™ Digital Controller Monitors & Controls All Functions
  • Provides system status for wireless monitors & Mobile Link™
  • Sound Attenuated Weather Proof Enclosure
  • Attractive styling with lockable access doors
  • Incorporates electrostatically applied epoxy paint technology
  • Sound dampening enclosure limits sound pressure to a low 62dB(A)
  • 12" flexible fuel line and manual included
  • Built-in Battery Charger (Battery Sold Separately)
  • Automatic Transfer Switch - ATS (Sold Separately)
  • Select the ideal ATS & PMM™ modules for load shed capabilities
  • Automatic Operation Only & Listed to UL2200 Standards For Safety
  • 5-Year Limited Warranty & 24/7/365 Customer Care
Specifications
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
8000 Watts
Surge Watts
8000 Watts
Fuel Type
LP/Natural Gas
NG Power Capacity
7000 Watts
LP Power Capacity
8000 Watts
NG Fuel Consumption @ 50% Load
77 ft³/hr
NG Fuel Consumption @ 100% Load
121 ft³/hr
LP Fuel Consumption @ 50% Load
0.94 gallons/hr
LP Fuel Consumption @ 100% Load
1.42 gallons/hr
Rated Amps
33 Amps
Decibel Rating @ 7m Learn More
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
62 dbA
Transfer Switch
Automatic (Not Included)
Battery
Not Included (525 CCA)
Enclosure
Steel
Cooling System
Air Cooled
UL Listed
Yes
Grade Type
Emergency
Engine
Engine Brand
Generac OHVI
CC
410 CC
Consumer Engine Warranty
5 Years
Commercial Engine Warranty
5 Years
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
Overview
Weight
340 Pounds
Made in USA
Yes
Consumer Warranty
5 Years
Commercial Warranty
5 Years
Product Style
Standby Generator
Product Length
48 Inches
Product Width
25 Inches
Product Height
29 Inches
UPC
696471062458
Product Specs
+
Specifications
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
8000 Watts
Surge Watts
8000 Watts
Fuel Type
LP/Natural Gas
NG Power Capacity
7000 Watts
LP Power Capacity
8000 Watts
NG Fuel Consumption @ 50% Load
77 ft³/hr
NG Fuel Consumption @ 100% Load
121 ft³/hr
LP Fuel Consumption @ 50% Load
0.94 gallons/hr
LP Fuel Consumption @ 100% Load
1.42 gallons/hr
Rated Amps
33 Amps
Decibel Rating @ 7m Learn More
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
62 dbA
Transfer Switch
Automatic (Not Included)
Battery
Not Included (525 CCA)
Enclosure
Steel
Cooling System
Air Cooled
UL Listed
Yes
Grade Type
Emergency
Engine
Engine Brand
Generac OHVI
CC
410 CC
Consumer Engine Warranty
5 Years
Commercial Engine Warranty
5 Years
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
Overview
Weight
340 Pounds
Made in USA
Yes
Consumer Warranty
5 Years
Commercial Warranty
5 Years
Product Style
Standby Generator
Product Length
48 Inches
Product Width
25 Inches
Product Height
29 Inches
UPC
696471062458
Reviews
(7)
+
Generac Guardian 6245 Reviews & Ratings
Product Q&A
(5)
+
Search Product Q&A's Answered by Jared, the Generator Expert
icon-social-fb1
+
How do you properly size a generator for a 1500 sq. ft. to 2000 sq. ft. home?
Kenneth F.
from Arkansas
December 13, 2016
Answer
Properly sizing the generator is crucial to the success of any generator installation and requires a good working knowledge of electricity and its characteristics, as well as the varying requirements of the electrical equipment comprising the load. A certified electrician needs to be consulted for proper sizing and installation of any generator. When analyzing the electrical load, consult the manufacturer’s nameplate on each major appliance or piece of equipment to determine its starting requirements in terms of amps and voltage which can be calculated to watts using Ohms Law (Amps x Volts = Watts). When choosing the generator output select a rating that is approximately 20 to 25% higher than the peak load (for example, if the load is about 8 kilowatts, select a 10 kW generator). A higher rated generator will operate comfortably at approximately 80% of its full capacity and will provide a margin of flexibility if the load increases in the future. Note: Applications that are commercial, all-electric homes, have heat pump systems or geothermal systems require special installation procedures and a certified electrician must be contacted to evaluate and install these types of systems. Home Standby Buyers Guide.

Check out our sizing video below:

Was this answer helpful?
Yes
Thumbs Up Icon
0
No
Thumbs Down Icon
0
+
I'm interested in the Generac 14 kw standby generator and I want to power it with natural gas. All your other Generac standby generators show a wattage loss of about 2kW when powered with natural gas, but this one does not show a loss in the specs I have reviewed. Is this a misprint in the specs or is this a true output? If I power it with natural gas will it deliver 12 kW or 14 kW?
Albert Leblanc
from Michigan
May 06, 2014
Answer
This is not a misprint in the specification. The unit will produce 14kW when operating on Natural Gas and LP as tested at the factory.

Also noted on the manufacturers specification sheets is the following....

"Maximum wattage and current are subject to and limited by such factors as fuel BTU/megajoule content, ambient temperature, altitude, engine power and condition, etc. Maximum power decreases about 3.5 percent for each 1,000 feet (304.8 meters) above sea level; and also will decrease about 1 percent for each 6° C (10° F) above 16° C (60°F)."

Specification sheets can be found on the individual product pages under the Specs tab and within the download document section.
Was this answer helpful?
Yes
Thumbs Up Icon
0
No
Thumbs Down Icon
0
+
Jim I have a 100 amp Pre-Nexus service rated transfer switch. Can I use this with a nexus generator? I've heard there is some special wiring for the battery charger to work
J. Depp
from California
November 04, 2013
Answer
Thank you for your interest in Electric Generators Direct!

There is a special kit that needs to be added to the switch to accept the 120V connection which provides the power to the internal generator controller for the charger. These kits are available from your local Generac dealer - Part Number: 0H92540SRV.


Was this answer helpful?
Yes
Thumbs Up Icon
0
No
Thumbs Down Icon
0
+
Hi, I am considering a purchase of 8Kw Generac. What does it mean by off-the-grid environment? How will I know if my house is also off-the-grid ? Thanks. Pramod
Pramod G.
from New Jersey
October 15, 2013
Answer
Thank you for your inquiry! The term off-grid refers to not being connected to a grid, mainly used in terms of not being connected to the main or national transmission grid in electricity. In electricity off-grid can be stand-alone systems (SHS) or mini-grids typically to provide a smaller community with electricity. If your home does not receive power from a utility company, then you are considered to be off-grid. See our video below:

Was this answer helpful?
Yes
Thumbs Up Icon
0
No
Thumbs Down Icon
0
+
Can the Nexus 200 amp Smart Switch be installed with a smaller (8KW) generator? We may be limited to the smaller generator due to propane supply issues, but love the load shedding concept.
Jim White
from Connecticut
May 12, 2013
Answer
Typically a smaller 8000 watt generator does not have the output capacity to handle a whole house application even when using the load control manager. The constant turning on and off equipment that the generator will never be able to run can be extremely harmful to the generator and to your equipment such as your AC or other larger loads.

We recommend consulting with a certified electrician to properly size the generator based on your actual needs and equipment in your home.

Yes, you can use the whole house switch but it is not recommended with a 8000 watt generator which is why manufacturers do not prepackage them together.

The 10kW unit is the largest prepackaged model that includes the whole house transfer switch but is also available with a select circuit.

Was this answer helpful?
Yes
Thumbs Up Icon
0
No
Thumbs Down Icon
0
