Gen-Tran 30-Amp PowerWeb Distribution Center (Outdoor 6 Outlets)

• Product Description
• Specs
• Reviews
• How-To Articles
• Manuals

Type

Amp Rating

30

Load Mgmt.

Enclosure

Type

Standart

Features

Features

• 30-Amp PowerWeb™ Temporary Power Distribution Center
• Outdoor reliable way to distribute power from a generator
• Ideal for construction sites
• 30-Amp PowerWeb to Satisfy Mid-Sized Contractors
• Includes L14-30 4-wire locking inlet to accommodate 7500 Watts
• Twistlock Outlets are Included for Downstrean Feeds
• Allows mulitple SR306 units to be daisy-chained together
• Includes 6 GFCI-protected NEMA 5-20Amp receptacles
• GFCIs are mounted in the outlets they protect
• GFCIs also detect open neutral conditiones as well as polarity
• Rounded Sled Frame with Aluminum Enclosure
• Easy to maneuver and corrosion-resistant
• Includes one L6-30Amp receptacle
• Certifications
• ETL Listed to UL standard 1640
• Meets OSHA requirements

Specifications

Plugs

Product Specs

Voltage

120/240 Single-Phase

Frequency

60 Hertz

Rated Watts

7500 Watts

Rated Amps

30 Amps

Max Generator Input

30 Amps

Maximum Wattage

7500 Watts

UL Listed

Yes

Transfer Switch Circuits

Circuit Breaker Protection

Each Circuit

Plugs

NEMA 5-20R - GFCI

3

NEMA L6-30R

1

NEMA L14-30R

1

Overview

Weight

35 Pounds

Product Length

22.5 Inches

Product Width

19 Inches

Product Height

11 Inches

Consumer Warranty

1 Year

Type

Amp Rating

30

Load Mgmt.

Enclosure

Type

Standart

Features

Features

• 30-Amp PowerWeb™ Temporary Power Distribution Center
• Outdoor reliable way to distribute power from a generator
• Ideal for construction sites
• 30-Amp PowerWeb to Satisfy Mid-Sized Contractors
• Includes L14-30 4-wire locking inlet to accommodate 7500 Watts
• Twistlock Outlets are Included for Downstrean Feeds
• Allows mulitple SR306 units to be daisy-chained together
• Includes 6 GFCI-protected NEMA 5-20Amp receptacles
• GFCIs are mounted in the outlets they protect
• GFCIs also detect open neutral conditiones as well as polarity
• Rounded Sled Frame with Aluminum Enclosure
• Easy to maneuver and corrosion-resistant
• Includes one L6-30Amp receptacle
• Certifications
• ETL Listed to UL standard 1640
• Meets OSHA requirements

Specifications

Plugs

Product Specs

Voltage

120/240 Single-Phase

Frequency

60 Hertz

Rated Watts

7500 Watts

Rated Amps

30 Amps

Max Generator Input

30 Amps

Maximum Wattage

7500 Watts

UL Listed

Yes

Transfer Switch Circuits

Circuit Breaker Protection

Each Circuit

Plugs

NEMA 5-20R - GFCI

3

NEMA L6-30R

1

NEMA L14-30R

1

Overview

Weight

35 Pounds

Product Length

22.5 Inches

Product Width

19 Inches

Product Height

11 Inches

Consumer Warranty

1 Year

Specifications

Plugs

Product Specs

Voltage

120/240 Single-Phase

Frequency

60 Hertz

Rated Watts

7500 Watts

Rated Amps

30 Amps

Max Generator Input

30 Amps

Maximum Wattage

7500 Watts

UL Listed

Yes

Transfer Switch Circuits

Circuit Breaker Protection

Each Circuit

Plugs

NEMA 5-20R - GFCI

3

NEMA L6-30R

1

NEMA L14-30R

1

Overview

Weight

35 Pounds

Product Length

22.5 Inches

Product Width

19 Inches

Product Height

11 Inches

Consumer Warranty

1 Year
