Gen-Tran 30-Amp (120/240V 8-Circuit) Prewired Manual Transfer Switch
Model: 3028
+
Share This Product
-
Product Description
-
9Reviews
-
1Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Type
Amp Rating
Circuits
10
Enclosure
Type
Manual
Amp Rating
30
Circuits
10
Enclosure
NEMA 1R
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
Features
Features
- Safest Way to Distribute Power
- Eliminates dangerous backfeeds and electrical overloads
- Easy Connection
- Plug generator cord directly into transfer switch
- Built-in Wattage Meter
- Track power input to ensure proper load balancing
- 8 Total Circuits
- Four 1-Pole (120 Volts) and Two 2-Pole (240 Volts)
- Switch can accommodate 10-circuits for future expansion
- Versatile Connection
- Allows hardwiring OR plug-in connection via power inlet
- 2-Pole, 60-Amp breaker required in existing load center
- Includes 30A 4-Prong Outlet (L14-30)
Specifications
Plugs
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
7500 Watts
Rated Amps
30 Amps
Enclosure
NEMA 1R
Number of Circuit Breakers
10
Max Generator Input
30 Amps
Maximum Wattage
7500 Watts
UL Listed
Yes
Overview
Weight
14 Pounds
Made in USA
Yes
Consumer Warranty
2 Years
Product Length
11.5 Inches
Product Width
9.25 Inches
Product Height
3.5 Inches
Transfer Switch Circuits
15A 120V
2
20A 120V
2
20A 240V
1
30A 240V
1
Plugs
NEMA L14-30R
1
Type
Amp Rating
Circuits
10
Enclosure
Type
Manual
Amp Rating
30
Circuits
10
Enclosure
NEMA 1R
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
Features
Features
- Safest Way to Distribute Power
- Eliminates dangerous backfeeds and electrical overloads
- Easy Connection
- Plug generator cord directly into transfer switch
- Built-in Wattage Meter
- Track power input to ensure proper load balancing
- 8 Total Circuits
- Four 1-Pole (120 Volts) and Two 2-Pole (240 Volts)
- Switch can accommodate 10-circuits for future expansion
- Versatile Connection
- Allows hardwiring OR plug-in connection via power inlet
- 2-Pole, 60-Amp breaker required in existing load center
- Includes 30A 4-Prong Outlet (L14-30)
Specifications
Plugs
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
7500 Watts
Rated Amps
30 Amps
Enclosure
NEMA 1R
Number of Circuit Breakers
10
Max Generator Input
30 Amps
Maximum Wattage
7500 Watts
UL Listed
Yes
Overview
Weight
14 Pounds
Made in USA
Yes
Consumer Warranty
2 Years
Product Length
11.5 Inches
Product Width
9.25 Inches
Product Height
3.5 Inches
Transfer Switch Circuits
15A 120V
2
20A 120V
2
20A 240V
1
30A 240V
1
Plugs
NEMA L14-30R
1
Product Specs
+−
Specifications
Plugs
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
7500 Watts
Rated Amps
30 Amps
Enclosure
NEMA 1R
Number of Circuit Breakers
10
Max Generator Input
30 Amps
Maximum Wattage
7500 Watts
UL Listed
Yes
Overview
Weight
14 Pounds
Made in USA
Yes
Consumer Warranty
2 Years
Product Length
11.5 Inches
Product Width
9.25 Inches
Product Height
3.5 Inches
Transfer Switch Circuits
15A 120V
2
20A 120V
2
20A 240V
1
30A 240V
1
Plugs
NEMA L14-30R
1
Product Q&A
(1)
+−
Search Product Q&A's
Answered by Jared, the Generator Expert
+−
My generator -Honda eu3000is - has all 120v outputs. Will the Gen Tran 2026 switch wire correctly for 120 v input.
Crispin Massay
from Alaska
January 18, 2011
Answer
According to the specifications for your Honda eu3000is, it has a 30A 125V twist lock receptacle which can accommodate a larger transfer switch. It is recommended to to upgrade to the Gen-Tran 30-Amp model instead and then use a 30A Power Inlet Box that matches the twist lock connection you have on your unit. Gen-Tran 30-Amp 3028
You will also need a proper Power Inlet Box Gen-Tran 30-Amp 53004
You will also need a proper Power Inlet Box Gen-Tran 30-Amp 53004
Was this answer helpful?
Yes
0
No
0
