Cummins RS125 Quiet Connect™ Series 125kW Standby Power Generator (277/480V 3-Phase)
Cummins RS125 Quiet Connect™ Series 125kW Standby Power Generator (277/480V 3-Phase)
+
Share This Product
-
Product Description
-
Reviews
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Grade
Style
Run Watts
125,000
Rated Watts
Voltage
277/480 Three-Phase
Fuel
Engine
Grade
Emergency
Style
Standby (Liquid Cooled)
Run Watts
125,000
Voltage
277/480 Three-Phase
Fuel
LP/Natural Gas
Engine
Cummins Onan
Features
Features
- Cummins Quiet Connect Series - RS125 Standby Power Generator
- For light commercial applications w/ 277/480V 3-Phase power
- Runs on Natural Gas (NG) or Liquid Propane (LP)
- Cummins 8.9L Turbocharged & Aftercooled Liquid-Cooled Engine
- 1800 RPM design provides reliability and fuel efficiency
- Brushless CA Series Alternator
- Provides +/- 1% voltage & +/- 0.25% frequency regulation
- As close to utility power as you can get in a standby generator
- Advanced Design Sound Attenuated Aluminum Enclosure
- Powder-coat paint helps prevent corrosion
- Aesthetically appealing withstands winds up to 180 MPH
- Designed for easy service & maintenance w/ hinged access doors
- PowerCommand® 2.3 Electronic Control
- Provides industry-leading self-diagnostic capabilities
- Easily see alarm status, messages, and output metering
- Flexible Exercise Mode
- Exercise at a time, frequency and duration that suits you
- Reducing unnecessary fuel consumption, emissions and noise
- Coolant Heater For Extreme Environmental Conditions (Included)
- Factory installed, allows for cold weather starts down to -40 °F
- Automatic Transfer Switch (Sold Separately)
- 2-Year Limited Warranty
- ^Please Note - Requires Loading Dock, Forklift or Crane For Delivery^
Specifications
Product Specs
Voltage
277/480 Three-Phase
Frequency
60 Hertz
Rated Watts
125000 Watts
Fuel Type
LP/Natural Gas
NG Power Capacity
125000 Watts
LP Power Capacity
125000 Watts
NG Fuel Consumption @ 50% Load
981.3 ft³/hr
NG Fuel Consumption @ 100% Load
1665.6 ft³/hr
LP Fuel Consumption @ 50% Load
10.87 gallons/hr
LP Fuel Consumption @ 100% Load
19.09 gallons/hr
Rated Amps
187.9 Amps
Decibel Rating @ 7m
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
71
Hour Meter
Yes
Transfer Switch
Automatic (Not Included)
Battery
Not Included
Enclosure
Aluminum
Circuit Breaker Size
250 Amps
Mounting Pad
Concrete (Not Included)
Cooling System
Liquid Cooled
UL Listed
Yes
Grade Type
Emergency
Engine
Engine Brand
Cummins Onan
Starting System
12v Auto Start
CC
8900 CC
Consumer Engine Warranty
2 Years
Commercial Engine Warranty
2 Years
Engine RPM
1800 RPM
Low Oil Alert/Shutdown
Yes
Overview
Weight
3915 Pounds
Made in USA
Yes
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
143 Inches
Product Width
40 Inches
Product Height
72 Inches
Additional Model Numbers
A058T801, A063A449
Grade
Style
Run Watts
125,000
Rated Watts
Voltage
277/480 Three-Phase
Fuel
Engine
Grade
Emergency
Style
Standby (Liquid Cooled)
Run Watts
125,000
Voltage
277/480 Three-Phase
Fuel
LP/Natural Gas
Engine
Cummins Onan
Features
Features
- Cummins Quiet Connect Series - RS125 Standby Power Generator
- For light commercial applications w/ 277/480V 3-Phase power
- Runs on Natural Gas (NG) or Liquid Propane (LP)
- Cummins 8.9L Turbocharged & Aftercooled Liquid-Cooled Engine
- 1800 RPM design provides reliability and fuel efficiency
- Brushless CA Series Alternator
- Provides +/- 1% voltage & +/- 0.25% frequency regulation
- As close to utility power as you can get in a standby generator
- Advanced Design Sound Attenuated Aluminum Enclosure
- Powder-coat paint helps prevent corrosion
- Aesthetically appealing withstands winds up to 180 MPH
- Designed for easy service & maintenance w/ hinged access doors
- PowerCommand® 2.3 Electronic Control
- Provides industry-leading self-diagnostic capabilities
- Easily see alarm status, messages, and output metering
- Flexible Exercise Mode
- Exercise at a time, frequency and duration that suits you
- Reducing unnecessary fuel consumption, emissions and noise
- Coolant Heater For Extreme Environmental Conditions (Included)
- Factory installed, allows for cold weather starts down to -40 °F
- Automatic Transfer Switch (Sold Separately)
- 2-Year Limited Warranty
- ^Please Note - Requires Loading Dock, Forklift or Crane For Delivery^
Specifications
Product Specs
Voltage
277/480 Three-Phase
Frequency
60 Hertz
Rated Watts
125000 Watts
Fuel Type
LP/Natural Gas
NG Power Capacity
125000 Watts
LP Power Capacity
125000 Watts
NG Fuel Consumption @ 50% Load
981.3 ft³/hr
NG Fuel Consumption @ 100% Load
1665.6 ft³/hr
LP Fuel Consumption @ 50% Load
10.87 gallons/hr
LP Fuel Consumption @ 100% Load
19.09 gallons/hr
Rated Amps
187.9 Amps
Decibel Rating @ 7m
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
71
Hour Meter
Yes
Transfer Switch
Automatic (Not Included)
Battery
Not Included
Enclosure
Aluminum
Circuit Breaker Size
250 Amps
Mounting Pad
Concrete (Not Included)
Cooling System
Liquid Cooled
UL Listed
Yes
Grade Type
Emergency
Engine
Engine Brand
Cummins Onan
Starting System
12v Auto Start
CC
8900 CC
Consumer Engine Warranty
2 Years
Commercial Engine Warranty
2 Years
Engine RPM
1800 RPM
Low Oil Alert/Shutdown
Yes
Overview
Weight
3915 Pounds
Made in USA
Yes
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
143 Inches
Product Width
40 Inches
Product Height
72 Inches
Additional Model Numbers
A058T801, A063A449
Product Specs
+−
Specifications
Product Specs
Voltage
277/480 Three-Phase
Frequency
60 Hertz
Rated Watts
125000 Watts
Fuel Type
LP/Natural Gas
NG Power Capacity
125000 Watts
LP Power Capacity
125000 Watts
NG Fuel Consumption @ 50% Load
981.3 ft³/hr
NG Fuel Consumption @ 100% Load
1665.6 ft³/hr
LP Fuel Consumption @ 50% Load
10.87 gallons/hr
LP Fuel Consumption @ 100% Load
19.09 gallons/hr
Rated Amps
187.9 Amps
Decibel Rating @ 7m
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
71
Hour Meter
Yes
Transfer Switch
Automatic (Not Included)
Battery
Not Included
Enclosure
Aluminum
Circuit Breaker Size
250 Amps
Mounting Pad
Concrete (Not Included)
Cooling System
Liquid Cooled
UL Listed
Yes
Grade Type
Emergency
Engine
Engine Brand
Cummins Onan
Starting System
12v Auto Start
CC
8900 CC
Consumer Engine Warranty
2 Years
Commercial Engine Warranty
2 Years
Engine RPM
1800 RPM
Low Oil Alert/Shutdown
Yes
Overview
Weight
3915 Pounds
Made in USA
Yes
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
143 Inches
Product Width
40 Inches
Product Height
72 Inches
Additional Model Numbers
A058T801, A063A449
