Kohler RDT Series 200-Amp Automatic Transfer Switch (Service Disconnect)

Kohler RDT Series 200-Amp Automatic Transfer Switch (Service Disconnect)
Our Price
Compare Prices
Shipping Info
Model: RDT-CFNC-200ASE
(Based on expert analysis, manufacturer ratings and customer reviews)
5.0 out of 55.0 out of 55.0 out of 55.0 out of 55.0 out of 5
Number of Reviews (1)
Write A Review
$1,164.00

In-Stock
Ships Wednesday, Nov 13th
Shipping Crate Icon
Free Shipping

In-Stock
Ships Wednesday, Nov 13th
Free Shipping
Free Shipping
Expedited Shipping
Expedited Shipping
*We currently CANNOT ship this product to Alaska, Hawaii or any destination outside of the United States
Share
  • Product Description
  • 1
    Reviews
  • 2
    Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Type
Service Disconnect
Amp Rating
200
Load Mgmt.
Enclosure
NEMA 3R
Type
Service Disconnect
Enclosure
NEMA 3R
Features
Features
  • Standard Features
  • Service Entrance Rated w/ a Square D type QOM circuit breaker
  • UL listed and CSA certified
  • Two-pole, single-phase, open-transition transfer switch
  • Double throw inherently interlocked design
  • Solid Neutral
  • 220/240 VAC, 50/60 Hz (jumper)
  • Contractor manually operable for maintenance purposes
  • NEMA 3R (outdoor) enclosure
  • MPAC™ 500 Controller Features
  • User-friendly interface and easy-to-find international symbols
  • LED indication of system faults
  • Test button (with or without load)
  • Exercise set button
  • Single-phase voltage sensing on both sources
  • Line-to-line frequency sensing
  • Fixed time delays
  • 5-year limited warranty
Specifications
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Amps
200 Amps
Transfer Switch Amperage
200-Amps
Enclosure
NEMA 3R
Transfer Switch Style
Service Disconnect
ATS Poles
2 Poles
Max Utility Input
200 Amps
Max Generator Input
200 Amps
UL Listed
Yes
Overview
Weight
37 Pounds
Consumer Warranty
5 Years
Product Length
33.8 Inches
Product Width
18.6 Inches
Product Height
6.4 Inches
UPC
650531953179
Type
Service Disconnect
Amp Rating
200
Load Mgmt.
Enclosure
NEMA 3R
Type
Service Disconnect
Enclosure
NEMA 3R
Features
Features
  • Standard Features
  • Service Entrance Rated w/ a Square D type QOM circuit breaker
  • UL listed and CSA certified
  • Two-pole, single-phase, open-transition transfer switch
  • Double throw inherently interlocked design
  • Solid Neutral
  • 220/240 VAC, 50/60 Hz (jumper)
  • Contractor manually operable for maintenance purposes
  • NEMA 3R (outdoor) enclosure
  • MPAC™ 500 Controller Features
  • User-friendly interface and easy-to-find international symbols
  • LED indication of system faults
  • Test button (with or without load)
  • Exercise set button
  • Single-phase voltage sensing on both sources
  • Line-to-line frequency sensing
  • Fixed time delays
  • 5-year limited warranty
Specifications
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Amps
200 Amps
Transfer Switch Amperage
200-Amps
Enclosure
NEMA 3R
Transfer Switch Style
Service Disconnect
ATS Poles
2 Poles
Max Utility Input
200 Amps
Max Generator Input
200 Amps
UL Listed
Yes
Overview
Weight
37 Pounds
Consumer Warranty
5 Years
Product Length
33.8 Inches
Product Width
18.6 Inches
Product Height
6.4 Inches
UPC
650531953179
Product Specs
+
Specifications
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Amps
200 Amps
Transfer Switch Amperage
200-Amps
Enclosure
NEMA 3R
Transfer Switch Style
Service Disconnect
ATS Poles
2 Poles
Max Utility Input
200 Amps
Max Generator Input
200 Amps
UL Listed
Yes
Overview
Weight
37 Pounds
Consumer Warranty
5 Years
Product Length
33.8 Inches
Product Width
18.6 Inches
Product Height
6.4 Inches
UPC
650531953179
Reviews
(1)
+
Kohler RDT-CFNC-200ASE Reviews & Ratings
Product Q&A
(2)
+
Search Product Q&A's Answered by Jared, the Generator Expert
icon-social-fb1
+
I have the 12res kohler generator. My electrician wants to use a 200 amp transfer switch because the house is on a 200 amp breaker. It looks as if the 200 amp is for 14 or higher generators.Will it be ok to use it on my generator. Thanks
Terry Harris
from Arkansas
October 10, 2012
Answer
As long as the 12kW generator is large enough to power your entire home without overloading the generator you can use the RDT switch.

Just keep in mind that proper generator sizing is based on 80% of the generators running capacity (12kW) allowing the unit the flexibility to handle large starting loads without overloading the unit.

Typically 12kW generators are not large enough to run and entire home which is why the switch lists 14kW or larger.

To compensate for the smaller generator you may want to purchase the Kohler Load Control Module which will shed large starting loads and lock out these loads if necessary.

Kohler Load Control Module
+
I would like to use Kohler 14kw res with Briggs and Stratton automatic transfer switch with main disconnect and power management. I think its symphony 2. Is it ok to use two different brands or do i have to use Kohler ATS? Thanks Jan
Jan
from Connecticut
March 10, 2012
Answer
These components are brand specific and are designed to communicate with one another. So, to answer your question, you would need to use a Kohler ATS.
