Kohler RDT Series 200-Amp Outdoor Automatic Transfer Switch w/ 24 Circuit Load Center

Model:

RDT-CFNC-0200B

Write a Review
$1,115.00
Free Shipping
  Learn More About Free Freight
Factory-Direct
Ships in 6-8 Weeks
Factory items ship direct from the manufacturer. Shipping times vary.
synchrony card logo
$20 / Month
With our 82 months 10.99% APR*
82 fixed monthly payments required.
Kohler RDT Series 200-Amp Outdoor Automatic Transfer Switch w/ 24 Circuit Load Center
Kohler RDT Series 200-Amp Outdoor Automatic Transfer Switch w/ 24 Circuit Load Center
Model: RDT-CFNC-0200B
$1,115.00
Features
Specifications
Reviews
Accessories
How-To Articles
Manuals
Share

Features

Type

Load Center

Amp Rating

200

Circuits

24

Voltage

120/240 Single-Phase

Enclosure

NEMA 3R



Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
  • Prewired Square D type QO load center
  • 200 amp load centers use up to 24 circuit breakers - not included
  • Standard Features
  • UL listed and CSA certified
  • Two-pole, single-phase, open-transition transfer switch
  • Double throw inherently interlocked design
  • Solid Neutral
  • 220/240 VAC, 50/60 Hz (jumper)
  • Contractor manually operable for maintenance purposes
  • NEMA 3R (outdoor) enclosure
  • MPACô 500 Controller Features
  • User-friendly interface and easy-to-find international symbols
  • LED indication of system faults
  • Test button (with or without load)
  • Exercise set button
  • Single-phase voltage sensing on both sources
  • Line-to-line frequency sensing
  • Fixed time delays
  • 5-year limited warranty
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov

Specifications

RDT-CFNC-0200B
specs product image PID-2205
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Amps
200 Amps
Enclosure
NEMA 3R
Number of Circuit Breakers
24
Transfer Switch Style
Select Circuit
ATS Load Prioritizing
Not Included
ATS Load Shedding
Not Included
ATS Poles
2 Poles
ATS Service Disconnect
No
Max Utility Input
200 Amps
Max Generator Input
200 Amps
UL Listed
Yes
Overview
Weight
18 Pounds
Consumer Warranty
5 Years
Product Depth
7 Inches
Product Width
16.4 Inches
Product Height
36.1 Inches
UPC
650531171450
