Cummins RS36 Quiet Connect™ Series 36kW Standby Power Generator (120/240V Single-Phase)

Model:

A051Y417

Recommended
Write a Review
$12,459.00
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 16-20 Weeks
Factory items ship direct from the manufacturer. Shipping times vary.
Shipping Details
  • Free to Lower 48 States
*We currently CANNOT ship this product to Alaska, Hawaii or any destination outside of the United States
$219 / Month
With our 82 months 10.99% APR*
82 fixed monthly payments required.
Available Add-Ons
Learn More Installation
Cummins RS36 Quiet Connect™ Series 36kW Standby Power Generator (120/240V Single-Phase)
Cummins RS36 Quiet Connect™ Series 36kW Standby Power Generator (120/240V Single-Phase)
Model: A051Y417
$12,459.00
Features
Specifications
Reviews
Accessories
How-To Articles
Manuals
Share

Features

Grade

Emergency

Style

Standby (Liquid Cooled)

Run Watts

36,000 Rated Watts

Voltage

120/240 Single-Phase

Fuel

LP/Natural Gas

Engine

Cummins Onan

  • Cummins Quiet Connect
  • Great for home & light commercial applications
  • Powerd By Cummins 2.4L Turbocharged Liquid-Cooled Engine
  • 1800 RPM design provides reliability and fuel efficiency
  • Brushless CA Series Alternator
  • Provides +/- 1% voltage & +/- 0.75% frequency regulation
  • As close to utility power as you can get in a standby generator
  • Advanced Design Sound Attenuated Aluminum Enclosure
  • Aesthetically appealing withstands winds up to 150 MPH
  • One of the quietest generators of its kind (63dB @ 7M)
  • PowerCommandŽ Electronic Control
  • Provides industry-leading self-diagnostic capabilities
  • Flexible Exercise Mode
  • Exercise at a time, frequency and duration that suits you
  • Reducing unnecessary fuel consumption, emissions and noise
  • Coolant Heater For Extreme Environmental Conditions (Included)
  • Factory installed, Allows for cold weather starts down to -40 °F
  • Automatic Transfer Switch (Sold Separately)
  • ^Please Note - Requires Loading Dock, Forklift or Crane For Delivery^
California residents see
Warning: This product can expose you to chemicals including Carbon black (airborne, unbound particles of respirable size) which is known to the State of California to cause Cancer, and Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

A051Y417
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
36000 Watts
Fuel Type
LP/Natural Gas
LP Power Capacity
36000 Watts
NG Fuel Consumption @ 50% Load
292.3 ft³/hr
NG Fuel Consumption @ 100% Load
472.3 ft³/hr
LP Fuel Consumption @ 50% Load
3.2 gallons/hr
LP Fuel Consumption @ 100% Load
5.1 gallons/hr
Rated Amps
150 Amps
Decibel Rating @ 7m Learn More
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
63 dbA
Transfer Switch
Automatic (Not Included)
Battery
Not Included (550 CCA)
Enclosure
Aluminum
Circuit Breaker Size
175 Amps
Mounting Pad
Concrete (Not Included)
Cooling System
Liquid Cooled
UL Listed
Yes
Grade Type
Emergency
Engine
Engine Brand
Cummins Onan
Starting System
12v Auto Start
CC
2400 CC
Consumer Engine Warranty
2 Years
Commercial Engine Warranty
2 Years
Engine RPM
1800 RPM
Low Oil Alert/Shutdown
Yes
Overview
Weight
1294 Pounds
Made in USA
Yes
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
94 Inches
Product Style
Standby Generator
Product Width
34 Inches
Product Height
45.5 Inches
Additional Model Numbers

RS36, A051Y417
