Cummins Onan QG 5500 - 5500 Watt EFI Commercial Mobile Generator EVAP (120/240V 30A)
Cummins Onan QG 5500 - 5500 Watt EFI Commercial Mobile Generator EVAP (120/240V 30A)
+
Share This Product
-
Product Description
-
1Reviews
-
1Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Grade
Style
Run Watts
5,500
Rated Watts
Voltage
120/240 Single-Phase
Fuel
Engine
Grade
Professional
Style
RV
Run Watts
5,500
Voltage
120/240 Single-Phase
Fuel
Gasoline
Engine
Cummins Onan
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
Features
Features
- EVAP Model - Meets CARB Tier 3 & EPA Phase 3 Standards
- 5.5 kW QG EFI Commercial Mobile Generator EVAP (120/240V - 30A)
- Quietest and lowest vibration generator set in its class
- Designed for tough commercial applications - Runs (2) ACs
- Electronic Fuel Injection (EFI) - Improves Hot & Cold Starting
- Provides clean, smooth running under all conditions
- Cummins Onan 4-Cycle OHV V-Twin Engine (.6 Gal/H @ 1/2 Load)
- Allows for start & run without AC output to conserve fuel
- Microprocessor Controlled w/ Automatic Safety Shutdowns
- Digital voltage regulatotion provides stabilty as loads change
- Self-diagnostic capability to simplify troubleshooting
- Low oil pressure, over/under speed, and overcurrent protection
- Sound-Attenuating Enclosure w/ Thru Flow Cooling System
- Lowers noise levels while providing cross-flow cooling
- NON EVAP MODEL- Generator Fuel Must Come from Chassis Fuel Tank
- Integral Control Panel w/ Waterproof Remote Connector
- Instant one-touch stop switch & Remote disable/continuous stop capability
- 4-Point Mounting System w/ Vibration Isolators & Universal Tray
- Added Features - Auto Choke, Full-Flow Oil Filter & Long Life Fuel Filter
- 2-Year Limited & 5-Year Drive Warranty (See Warranty Sheet)
- Requires Cummins Onan EFI Fuel Pump Kit "541-1002" (Not Included)
For Additional Models - Please Call Us @ 1-800-800-3317
Specifications
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Alternator
Brush
Auto Voltage Regulation
Yes
Rated Watts
5500 Watts
Fuel Type
Gasoline
Rated Amps
23 Amps
Decibel Rating @ 7m
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
Not Measured by Manufacturer
Hour Meter
Yes
Grade Type
Professional
Engine
Engine Brand
Cummins Onan
Starting System
12-Volt Button Start
CC
653 CC
Consumer Engine Warranty
2 Years
Commercial Engine Warranty
2 Years
Engine RPM
2400 RPM
Low Oil Alert/Shutdown
Yes
Cast Iron Sleeve
Yes
Overview
Weight
290 Pounds
Consumer Warranty
3 Years
Commercial Warranty
3 Years
Product Style
RV Generator
Product Length
33.6 Inches
Product Width
22.2 Inches
Product Height
16.7 Inches
Additional Model Numbers
5.5 HGJAD-6759, 5.5HGJAD-6759
Transfer Switch Circuits
Circuit Breaker Type
2-Pole - 30A (120/240V)
Grade
Style
Run Watts
5,500
Rated Watts
Voltage
120/240 Single-Phase
Fuel
Engine
Grade
Professional
Style
RV
Run Watts
5,500
Voltage
120/240 Single-Phase
Fuel
Gasoline
Engine
Cummins Onan
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
Features
Features
- EVAP Model - Meets CARB Tier 3 & EPA Phase 3 Standards
- 5.5 kW QG EFI Commercial Mobile Generator EVAP (120/240V - 30A)
- Quietest and lowest vibration generator set in its class
- Designed for tough commercial applications - Runs (2) ACs
- Electronic Fuel Injection (EFI) - Improves Hot & Cold Starting
- Provides clean, smooth running under all conditions
- Cummins Onan 4-Cycle OHV V-Twin Engine (.6 Gal/H @ 1/2 Load)
- Allows for start & run without AC output to conserve fuel
- Microprocessor Controlled w/ Automatic Safety Shutdowns
- Digital voltage regulatotion provides stabilty as loads change
- Self-diagnostic capability to simplify troubleshooting
- Low oil pressure, over/under speed, and overcurrent protection
- Sound-Attenuating Enclosure w/ Thru Flow Cooling System
- Lowers noise levels while providing cross-flow cooling
- NON EVAP MODEL- Generator Fuel Must Come from Chassis Fuel Tank
- Integral Control Panel w/ Waterproof Remote Connector
- Instant one-touch stop switch & Remote disable/continuous stop capability
- 4-Point Mounting System w/ Vibration Isolators & Universal Tray
- Added Features - Auto Choke, Full-Flow Oil Filter & Long Life Fuel Filter
- 2-Year Limited & 5-Year Drive Warranty (See Warranty Sheet)
- Requires Cummins Onan EFI Fuel Pump Kit "541-1002" (Not Included)
For Additional Models - Please Call Us @ 1-800-800-3317
Specifications
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Alternator
Brush
Auto Voltage Regulation
Yes
Rated Watts
5500 Watts
Fuel Type
Gasoline
Rated Amps
23 Amps
Decibel Rating @ 7m
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
Not Measured by Manufacturer
Hour Meter
Yes
Grade Type
Professional
Engine
Engine Brand
Cummins Onan
Starting System
12-Volt Button Start
CC
653 CC
Consumer Engine Warranty
2 Years
Commercial Engine Warranty
2 Years
Engine RPM
2400 RPM
Low Oil Alert/Shutdown
Yes
Cast Iron Sleeve
Yes
Overview
Weight
290 Pounds
Consumer Warranty
3 Years
Commercial Warranty
3 Years
Product Style
RV Generator
Product Length
33.6 Inches
Product Width
22.2 Inches
Product Height
16.7 Inches
Additional Model Numbers
5.5 HGJAD-6759, 5.5HGJAD-6759
Transfer Switch Circuits
Circuit Breaker Type
2-Pole - 30A (120/240V)
Product Specs
+−
Specifications
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Alternator
Brush
Auto Voltage Regulation
Yes
Rated Watts
5500 Watts
Fuel Type
Gasoline
Rated Amps
23 Amps
Decibel Rating @ 7m
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
Not Measured by Manufacturer
Hour Meter
Yes
Grade Type
Professional
Engine
Engine Brand
Cummins Onan
Starting System
12-Volt Button Start
CC
653 CC
Consumer Engine Warranty
2 Years
Commercial Engine Warranty
2 Years
Engine RPM
2400 RPM
Low Oil Alert/Shutdown
Yes
Cast Iron Sleeve
Yes
Overview
Weight
290 Pounds
Consumer Warranty
3 Years
Commercial Warranty
3 Years
Product Style
RV Generator
Product Length
33.6 Inches
Product Width
22.2 Inches
Product Height
16.7 Inches
Additional Model Numbers
5.5 HGJAD-6759, 5.5HGJAD-6759
Transfer Switch Circuits
Circuit Breaker Type
2-Pole - 30A (120/240V)
Product Q&A
(1)
+−
Search Product Q&A's
Answered by Jared, the Generator Expert
+−
Does the generator charge its own battery?
Joseph
from New York
April 21, 2020
Answer
A standard feature on this unit includes a 5-amp battery charger.
Was this answer helpful?
Yes
0
No
0
