Voltmaster LR60EL - LR60EL - 5500 Watt Electric Start Diesel Generator

Your Online Voltmaster Portable and Standby Generator Superstore.


Voltmaster Electric Generator and Generator Accessories
Model LR60EL
Voltmaster LR60EL - 5500 Watt Electric Start Diesel Generator

(1 Reviews)

Voltmaster LR60EL - 5500 Watt Electric Start Diesel Generator

Factory Direct Buy Factory Direct & Save
Ships in 4-7 Business Days
Check Arrival Times for the Voltmaster LR60ELEstimate Arrival
No Sales Tax on the Voltmaster LR60EL
Free Shipping on every Voltmaster LR60EL
Voltmaster LR60EL - 5500 Watt Electric Start Diesel Generator
Retail Price: $4,052.00
Click Here To Learn More About Our Factory Direct Savings Discount: -$1,002.01
Your Price: $3,049.99
Lift Gate Service +$0.00




Grade

Style
Run Watts
5,500
Rated Watts
Surge Watts
6,000
Starting Watts
Fuel
Engine
Need Help? Call Our Generator Experts.
10-HP/400cc Lombardini Diesel Engine
A workhorse on the job site

Electric Start w/ Recoil Backup (Battery Sold Separately)
Includes battery rack & cables

Cast Iron Cylinder Liner w/ Low Oil Pressure Shutdown
Provides added protection

Smooth Wave™
Provides <6% total harmonic distortion

5-Gallon Fuel Tank Provides Extended Run Time
14 hours @ half load & 10.5 hours @ full load

Professional Control Panel
GFCI outlets, circuit breakers, volt meter and hour meter

Full Power Switch
Choose between 120 volt or 120/240 volt AC power

12-Volt DC Battery Charging
Capable of external battery charging

Added Features
1" welded steel roll cage
Isolated and recessed control panel


Model
  Model Number:LR60EL
 Manufacturer:Voltmaster
 Made in USA:Yes
Engine
 Brand:Kohler
 Starting System:12-Volt Key Start w/ Recoil
 HP/CC:10 HP/400 cc
 Consumer Engine Warranty:2 Years
 Commercial Engine Warranty:2 Years
 Engine RPM:3600 RPM
 Low Oil Alert:Yes
 Cast Iron Sleeve:Yes
Product Specs
 Voltage120/240 Single-Phase
 Frequency:60 Hertz
 Alternator:Brushless
 Auto Voltage Regulation:Yes
 Fuel TypeDiesel
 Rated Amps:23 Amps @ 240 Volts (Single Phase)
 Tank Size:5 Gallons
 Run Time (50% Load):14 Hours
 Fuel Tank Material:Plastic
 Decibel Rating @ 7m:77 db(A)
 Hour Meter:Yes
 Voltage Meter:Yes
 Neutral Type:Bonded
 Battery:Not Included (400 CCA)
Overview
 Weight:182 Lbs. (82.56 kilograms)
 Dimensions:28"L x 22"W x 25"H
(71.12 x 55.88 x 63.50 cm)
 Consumer Warranty:2 Years
 Commercial Warranty:2 Years
Download Documents


Outlets
NEMA 5-20R (GFCI)
NEMA 5-20R (GFCI)

NEMA L14-20R
NEMA L5-30R

Need Help? Call Our Generator Experts.

*Ask Jim about this item. Sorry, no repair questions:


*Name:


*State:


*Email:


 Receive Weekly How-To Tips & Specials


*Required Field
  2 Questions
Q: Hello, how hard would it be to covert this unit to feed from a truck fuel tank?
by William Curtin from Ohio on February 25, 2011

A: For specific design questions you will have to contact the manufacturer. Voltmaster can be contacted at (800) 730-3927 - Note: Modifications to original design may void manufacturers warranty.
by Jim, Product Expert

Q: does the RL60EL have pressure lubrication and an oil filter?
by Frank Acello from Connecticut on January 19, 2011

A: This model does not have pressure lubrication or a spin-on oil filter. The larger models have this due to the engine size and is stated in the owner's manual which is listed in the specs tab for review.

by Jim, Product Expert

Overall
Rating
5.0 5.0 out of 55.0 out of 55.0 out of 55.0 out of 55.0 out of 5
(Based on 1 Reviews)
 Sort By
Write Review

Jim, the Generator Expert

,
Product Expert
Electric Generators Direct

5 out of 55 out of 55 out of 55 out of 55 out of 5

Electric Generators Direct Recommended
Jim's Recommendation

If your power application is going to involve many hours of operation OR if diesel fuel is your only fuel source option then a diesel powered generator set is best for you.

A diesel powered generator requires a little more attention to operate and maintain versus a gasoline powered generator. But if you are going to need power for several hours at a time, we feel this is the only way to go.

Diesel engines must be operated under 25% of the rated electrical load whenever the engine is running. If the diesel engine is left idling under no load or very small electrical loads (less than 25% of the generator rating) the diesel engine will not burn fuel properly. This will cause a condition known as "wet stacking" which is extreme vibration of the engine damaging the engine and other components.

To prevent "wet stacking" the load cell option is recommended. The load cell keeps an electrical load on the generator preventing this condition. When more than 25% load is put on the generator the load cell automatically shuts off. If the normal operation of the diesel generator always has at least 25% load on the generator, a load cell is not required.

If you decide to go this route, make sure you consider a load cell.
