The Reliance Controls 30-amp (120v 4-circuit) outdoor transfer switch has been discontinued and is not available for purchase at this time.

Reliance Controls 30-Amp (120V 4-Circuit) Outdoor Transfer Switch

Close
Reliance Controls Electric Generators and AccessoriesModel: R30114B
(Based on expert analysis, manufacturer ratings and customer reviews)
3.0 out of 53.0 out of 53.0 out of 53.0 out of 53.0 out of 5
1 Review
Share This Product
Plus 1 This Product
Tweet This Product
Pin It!



Product Discontinued Product Discontinued
  • Features
  • Specs
  • Q&A
  • 1
    Reviews
  • Articles
  • Accessories
Type
Manual
Amp Rating
NEMA L5-30R
Circuits
4
Enclosure
NEMA 3R
Safest Way to Distribute Power
Eliminates dangerous backfeeds and electrical overloads

Versatile Connection
Allows hardwiring OR plug-in connection via power inlet
Enclosure has 6 combination 1/2-inch and 3/4-inch knockouts

4 Total Circuits
Four 15-Amp Single-Pole (120 Volts) circuits

Steel Powder-Coated Cabinet
Padlockable cover can be closed with cord connected

UL Listed
Certified for use by Underwriter Laboratories
Product Specs
Voltage
120 Single-Phase
Frequency
60 Hertz
Rated Watts
3750 Watts
Rated Amps
30 @ 120 Volts (Single Phase) Amps
Enclosure
NEMA 3R
Conduit Length
16
Number of Circuit Breakers
4
Max Generator Input
30 Amps
Maximum Wattage
3750 Watts
UL Listed
Yes
Transfer Switch Circuits
15A 120V
4
Circuit Breaker Protection
Each Circuit
Plugs
NEMA L5-30R
1
Overview
Made in USA
Yes
Weight
19 Pounds
Product Length
18.5 Inches
Product Width
7.5 Inches
Product Height
7 Inches
Consumer Warranty
1 Year
Model
R30114B
Download Documents


Outlets
NEMA L5-30R
Need Help? Ask Our Generator Experts.
View Accessories For This Product
Read Reviews
How To Library

Questions before buying? Ask Mike about this item. Sorry, do not submit repair related questions.

Reliance Controls R30114B Reviews & Ratings
Overall Rating
Features
3/5
Quality
2/5
Performance
3/5
Value
2/5
Overall
3.0 out of 53.0 out of 53.0 out of 53.0 out of 53.0 out of 5
Pros
Easy To Use (1)
Cons
Bad Instructions (1)
Low Quality (1)
1 Review  Sort by

Bert B.
Maitland, FL
Purchased from Electric Generators Direct
Purchased 7/8/13
REVIEWED
JUL.
29
2013
3 out of 53 out of 53 out of 53 out of 53 out of 5
Great Cabinet, Poor Switches
I purchased this switch box as it had the right cord connector I needed for a Honda EU3000i. The box is built solid but the switches are very cheap and don't feel right. Hard to know when you are in the off position versus Line / Gen positions. No instructions were included but a quick trip to YouTube and there was a video I needed. (Does Red or Black got to house breaker side?) One of the switches was sticking out because the cheap plastic mount came off.

I would not recommend this... more
Pros: Easy To Use
Cons: Low Quality, Bad Instructions
Bert Does Not Recommend This Product
Mike, the Generator Expert
Product Expert
Bert,
Here is a link the Owner's Manual.
We always suggest having a licensed electrician install any type of transfer switch.
more
Bert Would Recommend Electric Generators Direct To A Friend
