Guardian Ultra Source 17,500 Watt Emergency Power System

Model:

4583

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Guardian Ultra Source 17,500 Watt Emergency Power System
Guardian Ultra Source 17,500 Watt Emergency Power System
Model: 4583
Was $2,899.99
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

Electric Generators Direct expert image
Expert Recommended Accessories Selected by Alberto, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Grade

Emergency

Style

Portable

Run Watts

17,500 Rated Watts

Surge Watts

26,250
Starting Watts

Fuel

Gasoline

Engine

Generac

  • 26,250 Surge Watts
  • Powerful enough to start a five ton A/C unit
  • Will also start two 4-ton A/C units
  • Everything but the Electrician
  • Ultra Source 17.5 kW Electric Start Generator
  • Siemens 60-Amp Pre-wired 16 circuit manual transfer switch
  • 50-Amp power inlet box & 15' power cord
  • Electric Start
  • Starts with a simple press of a button (Battery included)
  • Automatic Idle Control
  • Reduces noise, increase fuel efficiency and extends life
  • Full Pressure Lubrication
  • Eliminates wear during startup and extends life
  • 16-Gallon Gas Tank
  • Generates up to 10 hours of electricity at half load
  • Portablility Kit
  • Includes 13" all terrain tires and heavy-duty lifting eye

Specifications

Plug Types
12-Amp DC
NEMA 5-20R (Wall-Type)
NEMA 5-20R (GFCI)
NEMA L5-30R
NEMA L5-30R
NEMA L14-30R
NEMA 14-50R
4583
specs product image PID-1267
Overview
Weight
525 Pounds
Made in USA
Yes
Consumer Warranty
2 Years
Commercial Warranty
1 Year
Product Style
Portable Generator
Product Length
48.5 Inches
Product Width
30.75 Inches
Product Height
38.5 Inches
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Alternator
Brushless
Auto Voltage Regulation
Yes
Rated Watts
17500 Watts
Surge Watts
26250 Watts
Fuel Type
Gasoline
Rated Amps
73 Amps
Portability Kit
Pneumatic Wheels
Tank Size
16 Gallons
Run Time @ 50% Load
10 Hours
Fuel Tank Material
Plastic
Fuel Gauge
Yes
Decibel Rating @ 7m Learn More
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
Not Measured by Manufacturer
Idle Control
Yes
Hour Meter
No
Voltage Meter
No
Lifting Eye
Yes
Transfer Switch
Manual (Included)
Transfer Switch Amperage
50-Amps
Battery
Included
Grade Type
Emergency
Engine
Engine Brand
Generac
Starting System
12-Volt Button Start
HP
33 HP
CC
922 CC
Consumer Engine Warranty
2 Years
Commercial Engine Warranty
1 Year
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
Cast Iron Sleeve
Yes
Transfer Switch Circuits
15A 120V
5
20A 120V
5
20A 240V
1
40A 240V
1
50A 240V
1
Plugs
12-Amp DC
1
NEMA 5-20R - Wall-Type
1
NEMA 5-20R - GFCI
1
NEMA L5-30R
2
NEMA L14-30R
1
NEMA 14-50R
1
