The Gen-Tran 50-amp non-metallic power inlet box w/ flip lid has been discontinued and is not available for purchase at this time.

Gen-Tran 50-Amp Non-Metallic Power Inlet Box w/ Flip Lid

Close
Gen-Tran Electric Generators and AccessoriesModel: 63654
(Based on expert analysis, manufacturer ratings and customer reviews)
3.9 out of 53.9 out of 53.9 out of 53.9 out of 53.9 out of 5
7 Reviews
Share This Product
Plus 1 This Product
Tweet This Product
Pin It!



Product Discontinued Product Discontinued
  • Features
  • Specs
  • Q&A
  • 7
    Reviews
  • Articles
  • Accessories
50-Amp Non-Metallic Power
Designed for generators up to 12,500 watts

Durable, Glass-Filled Nylon NEMA 3R Enclosure
4-Wire 50A 125/250V male inlet in NEMA conf. CS6365 on bottom

Flip-Up Lid Mounted on Bottom
Keeps out dirt, insects and moisture

Unit Maintains "Raintight" Rating When Cord Is Connected
Now required by most inspectors

99 Cubic Inches Of Wiring Room
Enclosure contains 6 knockouts for ultimate wiring flexibility

Compatible w/ Transfer Switch Model 501210

UL Listed
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
12500 Watts
Rated Amps
50 @ 240 Volts (Single Phase) Amps
Enclosure
NEMA 3R
Maximum Wattage
12500 Watts
UL Listed
Yes
Plugs
CS6369 - 50-Amp Twistlock
1
Overview
Weight
2 Pounds
Product Length
5 Inches
Product Width
6 Inches
Product Height
5 Inches
Consumer Warranty
2 Years
UPC
764260636545
Model
63654
Download Documents


Outlets
CS6369 (50-Amp Twistlock)
Need Help? Call Our Generator Experts.
View Accessories For This Product
Read Reviews
How To Library

Questions before buying? Ask Mike about this item. Sorry, do not submit repair related questions.

Gen-Tran 63654 Reviews & Ratings
7 Reviews  Sort by

Dan
REVIEWED
JAN.
17
2013
5 out of 55 out of 55 out of 55 out of 55 out of 5
Works Great
I had this inlet box professionally installed. I did, however, open the box and inspect the insides upon arrival. It's a tight fit inside the box and the heavy gauge wire requires muscular fingers to install the conductors.

Take your time and you'll get it wired. After the electrician had the inlet installed, I tested the fit of the 25 foot, 50 amp generator cable (Generac part #6389). The first try the fitting was very tight and took quite a bit of work to get the plug to go in the... more
Was this review helpful?
00
Don
Purchased from Electric Generators Direct
Purchased 4/5/12
REVIEWED
APR.
27
2012
5 out of 55 out of 55 out of 55 out of 55 out of 5
Generator Plug
Works as planed.
Was this review helpful?
00
Chris
Tuxedo, NY
Purchased from Electric Generators Direct
Purchased 1/16/12
REVIEWED
MAR.
02
2012
5 out of 55 out of 55 out of 55 out of 55 out of 5
Great Outlet
Just installed the gen tran 50amp inlet outlet. There is plenty of room in this enclosure to wire the outlet. Nice unit. Highly recommend this to anyone. As long as you take your time and keep wires neat there is no reason why you would run into problems with the install. I give this 5stars and two thumbs up.
Was this review helpful?
00
Maryann Arrien
Putnam Valley, NY
Purchased from Electric Generators Direct
Purchased 12/1/11
Total Reviews
3 Reviews
REVIEWED
JAN.
18
2012
5 out of 55 out of 55 out of 55 out of 55 out of 5
Inlet Box Connection Too Tight - Wouldn't Twist
As another review said, it is very tight in there for the wires. The inlet model I have ending in a 4, (model 64654) requires you to take the connector and the flip cover off, wire it, and reassemble with 3 screws in the bottom. Getting the 3 screws back in the threaded holes was tough. I had to take the unit off the wall, and brace the top of it against the house to get the 3 screws to go back in. If you have no other choice than this inlet box, be sure to trim the wires back as much as... more
Was this review helpful?
00
Rich
Garrison, NY
Total Reviews
2 Reviews
REVIEWED
OCT.
11
2011
5 out of 55 out of 55 out of 55 out of 55 out of 5
Good Product, Simple Connections
This product was easy to use. The plugs connections are color coded. All you need to do is strip the wire, insert in the appropriate color and screw down. For a 50 amp connection you are using 6 gauge wire so don't keep the wires too long and you'll have plenty of room in the box without issues.
Was this review helpful?
00
John
Oketo, KS
REVIEWED
JAN.
05
2011
1 out of 51 out of 51 out of 51 out of 51 out of 5
Not Enough Room
There is not enough room in the box for the wiring. The box needs to be several inches taller.

We were very disappointed that we could not get the old Midwest version that we used to get from you, there was a lot more room for the wiring.
Was this review helpful?
00
John
Oketo, KS
REVIEWED
JAN.
05
2011
1 out of 51 out of 51 out of 51 out of 51 out of 5
Not Enough Room
There is not enough room in the box for the wiring. The box needs to be several inches taller.

We were very disappointed that we could not get the old Midwest version that we used to get from you, there was a lot more room for the wiring.
